General data:
Type: SS - Attack/Fleet Submarine Max Depth: -250 m
Commissioned: 2014 Length: 77.2 m
Beam: 8.5 m Draft: 5.5 m
Crew: 65 Displacement: 3000 t
Propulsion: AIP Motor Max Speed: 20 kt
Sensors / EW:
China SQG-2B [DUUX 5] - (Han) Hull Sonar, Passive-Only
Hull Sonar, Passive-Only Ranging Flank Array Search & Track
Max Range: 74.1 km
China SQC-1 [DSUV 2H + DUUA 2D] - (DSUV 22 System, Han) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 74.1 km
China Type 921-A Golf Ball - (Submarine, Stop Light) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
Snoop Tray 2 [MRK-50E Kaskad] - (Export) Radar
Radar, Surface Search, Short-Range
Max Range: 37 km
TSM 2243 - (DUUG-5, Assoc w/ DSUV 22/TSM 2233) Acoustic Intercept (Active Sonar Warning)
Acoustic Intercept
Max Range: 66.7 km
Generic Submarine Periscope, Optical - (2000s, 1.5x/12x Zoom) Visual
Visual, Surveillance Periscope
Max Range: 41.7 km
Generic Submarine Periscope, LLTV - (2000s/2010s, Gen 3, 1.5x/8x Zoom) Visual
LLTV, Surveillance & Navigation Camera
Max Range: 41.7 km
Weapons:
Generic Acoustic Decoy - (2000s, Noisemaker / Bubble Screen) Decoy (Expendable)
Subsurface Max: 1.9 km.
Yu-6 - (2006, ASW & ASuW, Submarine) Torpedo
Surface Max: 11.1 km. Subsurface Max: 11.1 km.
YJ-82 [YJ-802Q] - (1995) Guided Weapon
Surface Max: 129.6 km.
