General data: | |
---|---|
Type: SSN - Nuclear Powered Attack Submarine | Max Depth: -300 m |
Commissioned: 1991 | Length: 109.7 m |
Beam: 10.1 m | Draft: 9.75 m |
Crew: 129 | Displacement: 6255 t |
Propulsion: 1x S6G Nuclear Reactor | Max Speed: 32 kt |
Sensors / EW: |
---|
AN/WLR-9A - (AN/BLR-14, Sonar Warning Receiver) Acoustic Intercept (Active Sonar Warning) Acoustic Intercept & Torpedo Warning Max Range: 27.8 km |
AN/BPS-15A - (AN/BLR-14, Sonar Warning Receiver) Radar Radar, Surface Search, Medium-Range Max Range: 166.7 km |
AN/BRD-7 - (AN/BLR-14, Sonar Warning Receiver) ESM HF/DF Max Range: 926 km |
AN/TB-23/BQ - (1990, 4000ft Thin Line, Narwhal & Los Angeles Only) TASS, Passive-Only Towed Array Sonar System TASS, Passive-Only Thin Line Towed Array Sonar System Max Range: 129.6 km |
AN/TB-16B - (1990, 2600ft Fat-Line) TASS, Passive-Only Towed Array Sonar System TASS, Passive-Only Fat Line Towed Array Sonar System Max Range: 129.6 km |
AN/BQQ-5D(V)1 [BQS-13] - (1990, Los Angeles, Accot w TB-16B & TB-23, AN/BQS-15, AN/WLR-9) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 74.1 km |
AN/WLR-10 - (Assoc w AN/ALR-8) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
AN/BQS-15 - (Assoc w AN/ALR-8) Hull Sonar, Active-Only Hull Sonar, Active-Only Under-Ice Navigation and Mine & Obstacle Avoidance Max Range: 0.7 km |
AN/BLD-1 - (Assoc w AN/BRD-7) ESM HF/DF w/ OTH Targeting Max Range: 926 km |
AN/WLR-8(V)6 - (Los Angeles) ESM ELINT Max Range: 926 km |
Type 18 Periscope Optical Component - (Baseline, 1970s+) Visual Visual, Surveillance Periscope Max Range: 41.7 km |
Generic Submarine Periscope, LLTV - (1980s/1990s, Gen 2, 1.5x/4x Zoom) Visual LLTV, Surveillance & Navigation Camera Max Range: 41.7 km |
Weapons: |
---|
Mk48 Mod 5 ADCAP -
(1991) Torpedo Surface Max: 38.9 km. Subsurface Max: 38.9 km. |
UGM-109C Tomahawk Blk II TLAM -
(1987-1998, TT) Guided Weapon Land Max: 2500.2 km. |
UGM-109D Tomahawk Blk II TLAM -
(1989-1998, TT) Guided Weapon Land Max: 2500.2 km. |
UGM-84D Harpoon IC -
(1986) Guided Weapon Surface Max: 138.9 km. |
UGM-109D Tomahawk Blk II TLAM -
(1989-1998, VLS) Guided Weapon Land Max: 2500.2 km. |
UGM-109C Tomahawk Blk II TLAM -
(1987-1998, VLS) Guided Weapon Land Max: 2500.2 km. |
ADC Mk2 Mod 0 Torpedo Decoy -
(1979, 3-inch) Decoy (Expendable) Subsurface Max: 1.9 km. |
