| General data: | |
|---|---|
| Type: SS - Attack/Fleet Submarine | Max Depth: -300 m |
| Commissioned: 1978 | Length: 67.6 m |
| Beam: 6.8 m | Draft: 5.4 m |
| Crew: 54 | Displacement: 1490 t |
| Propulsion: Electric Motors | Max Speed: 20 kt |
| Sensors / EW: |
|---|
| DUUX 2A - (Type 2005) Hull Sonar, Passive-Only Hull Sonar, Passive-Only Ranging Flank Array Search & Track Max Range: 27.8 km |
| DSUV 22 [DSUV 2H + DUUA 2D] - (TMS 2233, TMS 2263, TMS 2271R, TSM 2272, Type 2040) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 74.1 km |
| ARUR 10 [DR 2000U] - (ARUD 10) ESM ELINT Max Range: 926 km |
| DRUA 33C Calypso III [TRS 3100] - (ARUD 10) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 37 km |
| DUUG 5 - (TSM 2243, Assoc w DUUG 6, Used w DSUV 22/TSM 2233) Acoustic Intercept (Active Sonar Warning) Acoustic Intercept, Surveillance Max Range: 27.8 km |
| DUUG 6 [M5] - (TSM 2243, Assoc w DUUG 6, Used w DSUV 22/TSM 2233) Acoustic Intercept (Active Sonar Warning) Acoustic Intercept Max Range: 66.7 km |
| Generic Submarine Periscope, Optical - (1970s, 1.5x/8x Zoom) Visual Visual, Surveillance Periscope Max Range: 41.7 km |
| Generic Submarine Periscope, LLTV - (1970s, Gen 1, 1x/2x Zoom) Visual LLTV, Surveillance & Navigation Camera Max Range: 27.8 km |
| Weapons: |
|---|
| F17 Mod 1 -
(1973, 550mm, Submarine Only, Offensive) Torpedo Surface Max: 7.4 km. Subsurface Max: 7.4 km. |
| Generic Acoustic Decoy -
(1970s, Noisemaker / Bubble Screen) Decoy (Expendable) Subsurface Max: 1.9 km. |
