General data: | |
---|---|
Type: FFG - Guided Missile Frigate | Max Speed: 28 kt |
Crew: 90 | Length: 84 m |
Beam: 10.3 m | Draft: 3.1 m |
Displacement Full: 1320 t | Displacement: 1100 t |
Operator: Navy | Commissioned: 1998 |
Propulsion: 1x MTU 20V 956 TB82 Diesel, 1x General Electric LM-2500 Gas Turbine, CODOG |
Sensors / EW: |
---|
PMS 26 - (Modified Type 195, Type 164/174 Replacement) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 5.6 km |
Scanter 009 - (Modified Type 195, Type 164/174 Replacement) Radar Radar, Surface Search & Navigation Max Range: 46.3 km |
Cutlass B1 - (Assoc w Scorpion jammer/Anaren antenna) ESM ELINT w/ OTH Targeting Max Range: 926 km |
Telegon [Generic] - (For ships with unspecified Telegon gear) ESM HF/DF Max Range: 926 km |
AN/AAQ-22 BRITE Star - (Navalized) Infrared Infrared, Surveillance Camera Max Range: 55.6 km |
TRS-3D/16MS - (Navalized) Radar Radar, Air & Surface Search, 3D Medium-Range Max Range: 185.2 km |
9LV200 Mk1 [Radar] - (Group, PE 723 Radar, 9LV202, 212, 218, RAKEL 203, ArtE-722) Radar Radar, FCR, Weapon Director Max Range: 14.8 km |
9LV200 Mk1 [Laser Rangefinder] - (Group, PE 723 Radar, 9LV202, 212, 218, RAKEL 203, ArtE-722) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 7.4 km |
9LV200 Mk1 [IR] - (Group, PE 723 Radar, 9LV202, 212, 218, RAKEL 203, ArtE-722) Infrared Infrared, Weapon Director Camera Max Range: 148.2 km |
9LV200 Mk1 [TV Camera] - (Group, PE 723 Radar, 9LV202, 212, 218, RAKEL 203, ArtE-722) Visual Visual, Weapon Director TV Camera Max Range: 148.2 km |
9GA209 [9GR600] - (9LV200 Mk2) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 55.6 km |
Mk95 [EO] - (Mk6 Mod 0, Mk91 FCS) Visual Visual, Target Tracking and Identification TV Camera Max Range: 148.2 km |
Mk95 [Radar] - (MFCR, Mk91 FCS) Radar Radar Illuminator, Medium-Range Max Range: 118.5 km |
Weapons: |
---|
Depth Charge [Generic] -
Depth Charge Subsurface Max: 0.2 km. |
20mm/70 Oerlikon Mk7 Burst [20 rnds] -
Gun Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km. |
76mm/62 Compact HE Burst [4 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
RGM-84A Harpoon IP -
(1977) Guided Weapon Surface Max: 120.4 km. |
Mk186 TORCH Flare [Seduction] -
(1979) Decoy (Expendable) Surface Max: 1.9 km. |
Mk214 Sea Gnat Chaff [Seduction] -
(1987) Decoy (Expendable) Surface Max: 1.9 km. |
Mk216 Sea Gnat Chaff [Distraction] -
(1988) Decoy (Expendable) Surface Max: 1.9 km. |
RIM-7P Sea Sparrow -
(1994) Guided Weapon Air Max: 25.9 km. Surface Max: 25.9 km. |
