General data: | |
---|---|
Type: FFL - Corvette | Max Speed: 24 kt |
Crew: 113 | Length: 86.6 m |
Beam: 10.5 m | Draft: 3.2 m |
Displacement Full: 1285 t | Displacement: 1029 t |
Operator: Navy | Commissioned: 2006 |
Propulsion: 2x Wärtsilä NSD BM230-20DVM Diesels | Decommissioned: 2019 |
Sensors / EW: |
---|
Telegon 4 - (AK 1200) ESM HF/DF Max Range: 926 km |
DE 1167 - (1985, AN/SQS-58, Integrated Hull) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 9.3 km |
MM/SLQ-747 [ESM] - (INS-3) ESM ELINT Max Range: 926 km |
MM/SLQ-747 [ECM] - (TQN-2) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
MM/SPS-774 [RAN-10S Pluto] - (NA-30B/E Search) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 166.7 km |
MM/SPN-728(V)2 - (Navigation & Helicopter Control) Radar Radar, Air & Surface Search, 3D Short-Range Max Range: 74.1 km |
NA-18 [LLTV] - (Group, Minerva) Visual LLTV, Weapon Director Max Range: 74.1 km |
NA-18 [IR] - (Group, Minerva) Infrared Infrared, Weapon Director Camera Max Range: 37 km |
NA-18 [Laser Rangefinder] - (Group, Minerva) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 18.5 km |
Galileo OG 30 [FLIR] - (Aspide-Only) Infrared Infrared, Target Tracking and Identification Camera Max Range: 185.2 km |
MM/SPG-76 [Radar] - (RTN-30X, Aspide) Radar Radar Illuminator, Medium-Range Max Range: 46.3 km |
Weapons: |
---|
Aspide -
(1980, SAM) Guided Weapon Air Max: 18.5 km. Surface Max: 18.5 km. |
76mm/62 Compact HE Burst [4 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
AN/SLQ-25 Nixie -
Decoy (Towed) Surface Max: 1.9 km. |
Barricade Chaff -
Decoy (Expendable) Surface Max: 1.9 km. |
Barricade Flare -
Decoy (Expendable) Surface Max: 1.9 km. |
