General data: | |
---|---|
Type: FFL - Corvette | Max Speed: 32 kt |
Crew: 43 | Length: 57 m |
Beam: 8 m | Draft: 2 m |
Displacement Full: 425 t | Displacement: 380 t |
Operator: Navy | Commissioned: 2007 |
Propulsion: 3x MTU 16V 396 TB94 Diesels |
Sensors / EW: |
---|
Pilot Mk.2 - (LPI) Radar Radar, Surface Search & Navigation Max Range: 88.9 km |
TSM 2643 Salmon - (LPI) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 7.4 km |
SA 950 - (Elma attack sonar) Hull Sonar, Active-Only Hull Sonar, Active-Only Mine Hunting & ASW Mortar Fire Control [Detection & Classification] Max Range: 1.1 km |
PS-76 & PS 722 [Sea Giraffe 150 HC & ArtE 722E Surveillance] - (1990, CA/SPS-505) Radar Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface Max Range: 100 km |
RAN-1010 MBAT [SEWS] - (Rafael, RAN-1101, 1110 or Shark system) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
C-Pearl-M - (Mini) ESM ELINT w/ OTH Targeting Max Range: 926 km |
CEROS 200 Tracker [9LV Mk3 Basic] - (Group, PE 723 Radar, 9GR400) Radar Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range Max Range: 46.3 km |
EOS 500 [CCD] - (Group, PE 723 Radar, 9GR400) Visual LLTV, Weapon Director Max Range: 185.2 km |
EOS 500 [IR Camera] - (Group, PE 723 Radar, 9GR400) Infrared Infrared, Weapon Director Camera Max Range: 185.2 km |
EOS 500 [Laser Rangefinder] - (Group, PE 723 Radar, 9GR400) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 7.4 km |
Weapons: |
---|
Philax Chaff -
Decoy (Expendable) Surface Max: 1.9 km. |
Philax Flare -
Decoy (Expendable) Surface Max: 1.9 km. |
RB 15M Mk2 -
(1997) Guided Weapon Surface Max: 148.2 km. |
57mm/70 Bofors Mk2 GP Burst [4 rnds] -
Gun Air Max: 2.2 km. Surface Max: 9.3 km. Land Max: 9.3 km. |
40mm/70 Single Bofors Burst [4 rnds] -
Gun Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km. |
Tp 432 -
(1990, Air & Ship, Light) Torpedo Subsurface Max: 7.4 km. |
