General data:
Type: CVA - Attack Carrier Max Speed: 33 kt
Crew: 2800 Length: 304 m
Beam: 36.9 m Draft: 11.8 m
Displacement Full: 64000 t Displacement: 45000 t
Operator: Navy Commissioned: 1985
Propulsion: 12x Boilers, 4x Westinghouse Steam Turbines Decommissioned: 1990
Sensors / EW:
AN/WLR-11 - (RWR for AN/WLR-1G, Improved AN/WLR-3 & AN/ALR-52) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
AN/SPS-48C - (1978) Radar
Radar, Air Search, 3D Long-Range
Max Range: 407.4 km
LN-66LP - (AN/SPS-59, 10kW) Radar
Radar, Surface Search, Short-Range
Max Range: 59.3 km
AN/SPS-65(V)1 - (BPDMS, MPDR-45, AN/SPS-58) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 64.8 km
AN/SPS-49(V)5 NTU - (BPDMS, MPDR-45, AN/SPS-58) Radar
Radar, Air Search, 2D Long-Range
Max Range: 463 km
AN/ULQ-6C - (AN/SLQ-26) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
AN/SPN-43A - (1976) Radar
Radar, Shipboard Air Traffic Control (SATC)
Max Range: 129.6 km
AN/WLR-1C - (AN/SLQ-26) ESM
ELINT
Max Range: 926 km
Weapons:
20mm/85 Mk15 Phalanx Blk 0 Burst [200 rnds] - Gun
Air Max: 1.5 km.
Mk182 SRBOC Chaff [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
Mk186 TORCH Flare [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
AN/SLQ-25 Nixie - Decoy (Towed)
Surface Max: 1.9 km.
7.62mm MG Burst [20 rnds] - (Ship & Facility) Gun
Surface Max: 0.4 km. Land Max: 0.4 km.
