| General data: | |
|---|---|
| Type: DDG - Guided Missile Destroyer | Max Speed: 29 kt |
| Crew: 280 | Length: 155.0 m |
| Beam: 17.0 m | Draft: 6.1 m |
| Displacement Full: 7500 t | Displacement: 6900 t |
| Operator: Navy | Commissioned: 2006 |
| Propulsion: 2x MTU 2V 1163 TB83 Diesels, 2x DN-80 Gas Turbines, CODOG |
| Sensors / EW: |
|---|
| China Type 347 - (GFCR, 100mm, EFR-1, Rice Lamp) Radar Radar, FCR, Weapon Director Max Range: 37 km |
| China Type 346 PAR [HQ-9] - (Kvant/APAR) Radar Radar, FCR, Surface-to-Air, Medium-Range Max Range: 277.8 km |
| China BM/HZ 8610 [DR 4000] - (Kvant/APAR) ESM ELINT w/ OTH Targeting Max Range: 926 km |
| China Type 360 - (Sea Tiger, SR-60, S-3, Seagull-S) Radar Radar, Air & Surface Search, 2D Medium-Range Max Range: 250 km |
| Bull Nose [MGK-335M Platina] - (1981, Assoc w Mare Tail & Steer Hide) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search Max Range: 27.8 km |
| China Type 517H-1 Knife Rest - (Pea Sticks) Radar Radar, Air Search, 2D Long-Range Max Range: 333.4 km |
| China SJG-206 TASS - (Assoc w SJD-9, Surface Units) TASS, Passive-Only Towed Array Sonar System TASS, Passive-Only Towed Array Sonar System Max Range: 129.6 km |
| China Type NRJ-6A [ECM] - (Group, Type 052C/D) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
| China Type NRJ-6A [RWR] - (Group, Type 052C/D) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| Band Stand [Mineral-ME1, Active Element] - (SSM FCR, 3M82?) Radar Radar, Target Indicator, Surf-to-Surf Max Range: 250 km |
| Band Stand [Mineral-ME2, Passive Element] - (SSM FCR, 3M82?) ESM ELINT w/ OTH Targeting Max Range: 444.5 km |
| Band Stand [Mineral-ME3, Exchange & Orientation Element] - (SSM FCR, 3M82?) Radar Radar, Surface Search, Short-Range Max Range: 29.6 km |
| China Type 760 - (SSM FCR, 3M82?) Radar Radar, Surface Search & Navigation Max Range: 46.3 km |
| Weapons: |
|---|
| 100mm/55 H/PJ-87 HECVT -
Gun Air Max: 2.8 km. Surface Max: 13 km. Land Max: 13 km. |
| 100mm/55 H/PJ-87 HE -
Gun Surface Max: 13 km. Land Max: 13 km. |
| 30mm China H/PJ-12 [Type 730, 240 rnds] -
(China, Goalkeeper Copy) Gun Air Max: 1.9 km. Surface Max: 2.8 km. |
| Yu-7 -
(China, 1998?) Torpedo Subsurface Max: 3.7 km. |
| Generic Flare Rocket [Single Spectral] -
(Ship-only) Decoy (Expendable) Surface Max: 1.9 km. |
| Generic Chaff Rocket -
(Ship-only) Decoy (Expendable) Surface Max: 1.9 km. |
| HQ-9A -
(China) Guided Weapon Air Max: 148.2 km. |
| YJ-62 -
(2006, LR SSM) Guided Weapon Surface Max: 398.2 km. |
| China Towed Acoustic Decoy -
(2012+) Decoy (Towed) Surface Max: 1.9 km. |
