General data: | |
---|---|
Type: DDG - Guided Missile Destroyer | Max Speed: 31 kt |
Crew: 266 | Length: 144 m |
Beam: 16 m | Draft: 5.1 m |
Displacement Full: 4800 t | Displacement: 4200 t |
Operator: PLAN | Commissioned: 1995 |
Propulsion: 2x MTU 12V 1163 TB83 Diesels, 2x GE LM-2500 Gas Turbines, CODOG |
Sensors / EW: |
---|
Crotale TV Tracker - (Group, Crotale FCR, Castor IIJ?) Visual Visual, Target Tracking and Identification TV Camera Max Range: 74.1 km |
China Type 345 [Radar] - (Crotale) Radar Radar, FCR, Surface-to-Air, Short-Range Max Range: 29.6 km |
Piranha [IR] - (Castor IIJ) Infrared Infrared, Target Tracking and Identification Camera Max Range: 148.2 km |
China Type 344 - (GFCR, 100/130mm, MR-34) Radar Radar, FCR, Weapon Director Max Range: 27.8 km |
DRBV 15 Sea Tiger [TRS 3001] - (GFCR, 100/130mm, MR-34) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 133.3 km |
China Type 347G Rice Bowl - (37mm, EFR-1) Radar Radar, FCR, Weapon Director Max Range: 37 km |
DE 1160B [DE 1164 Integrated Suite] - (DE 1160 Hull + DE 1163 VDS) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 9.3 km |
DE 1163 VDS [DE 1164 Integrated Suite] - (DE 1160 Hull + DE 1163 VDS) VDS, Active/Passive Sonar VDS, Active/Passive Variable Depth Sonar Max Range: 9.3 km |
China Type 362 - (Type 347S, ESR-1, SR-47A, MR-36) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 120.4 km |
China Type 518 Sea Eye - (Hai Ying, REL-1) Radar Radar, Air Search, 2D Medium-Range Max Range: 277.8 km |
Rapids [Improved Sphinx] - (Hai Ying, REL-1) ESM ELINT Max Range: 926 km |
China Type 984-1 [ECM] - (RAMSES Copy) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
China Type 984-1 [RWR] - (RAMSES Copy) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
Decca 1290 Master - (RAMSES Copy) Radar Radar, Surface Search & Navigation Max Range: 37 km |
Weapons: |
---|
FQF-2500 Anti-Torpedo Depth Charge Salvo [12 rnds] -
Depth Charge Subsurface Max: 1.9 km. |
100mm/56 Twin PJ33A Frag Burst [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
100mm/56 Twin PJ33A HE [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
YJ-8A [C-801A] -
(China, 1993) Guided Weapon Surface Max: 46.3 km. |
A.244 -
(1976) Torpedo Subsurface Max: 5.6 km. |
Generic Chaff Rocket -
(Ship-only) Decoy (Expendable) Surface Max: 1.9 km. |
HQ-7 Crotale [FM-80] Naval -
(China, 1990, CSA-4) Guided Weapon Air Max: 9.3 km. Surface Max: 9.3 km. |
37mm/63 Twin Burst [20 rnds] -
Gun Air Max: 1.9 km. Surface Max: 2.8 km. |
Mk182 SRBOC Chaff [Seduction] -
(1979) Decoy (Expendable) Surface Max: 1.9 km. |
Mk186 TORCH Flare [Seduction] -
(1979) Decoy (Expendable) Surface Max: 1.9 km. |
