| General data: | |
|---|---|
| Type: FFG - Guided Missile Frigate | Max Speed: 25 kt |
| Crew: 120 | Length: 96.6 m |
| Beam: 11.2 m | Draft: 4.5 m |
| Displacement Full: 1970 t | Displacement: 1670 t |
| Operator: Navy | Commissioned: 1988 |
| Propulsion: 2x Babcock & Wilcox Boilers, 2x Laval-Ljungstrom PN 20 Geared Steam Turbines |
| Sensors / EW: |
|---|
| Telegon 4 - (AK 1200) ESM HF/DF Max Range: 926 km |
| 9LV200 Mk2 [Radar] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Radar Radar, FCR, Weapon Director Max Range: 14.8 km |
| 9LV200 Mk2 [TV Camera] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Visual Visual, Weapon Director TV Camera Max Range: 148.2 km |
| 9LV200 Mk2 [IR] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Infrared Infrared, Weapon Director Camera Max Range: 148.2 km |
| 9LV200 Mk2 [Laser Rangefinder] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 7.4 km |
| TSM 2633 Spherion B - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 14.8 km |
| MPDR-45/1 - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Radar Radar, Air & Surface Search, 2D Medium-Range Max Range: 231.5 km |
| AR-700A(V)1 - (ASP-2000, Assoc w APECS II) ESM ELINT Max Range: 926 km |
| TSM 2633 Spherion A - (ASP-2000, Assoc w APECS II) VDS, Active/Passive Sonar VDS, Active/Passive Variable Depth Sonar Max Range: 29.6 km |
| Mk95 [EO] - (Mk6 Mod 0, Mk91 FCS) Visual Visual, Target Tracking and Identification TV Camera Max Range: 148.2 km |
| Mk95 [Radar] - (MFCR, Mk91 FCS) Radar Radar Illuminator, Medium-Range Max Range: 118.5 km |
| Decca 1226 - (MFCR, Mk91 FCS) Radar Radar, Surface Search & Navigation Max Range: 88.9 km |
| Weapons: |
|---|
| Terne III ASW Rocket Salvo [6 rnds] -
Rocket Subsurface Max: 4.6 km. |
| 20mm/80 Rhinemetall Mk20 Rh202 Burst [20 rnds] -
Gun Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km. |
| 76mm/50 Twin Frag Burst [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
| 76mm/50 Twin HE Burst [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
| 40mm/70 Single Bofors Burst [4 rnds] -
Gun Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km. |
| RIM-7M Sea Sparrow -
(1985) Guided Weapon Air Max: 25.9 km. Surface Max: 25.9 km. |
| RB 12 Penguin Mk1 -
(1972) Guided Weapon Surface Max: 27.8 km. |
| Mk214 Sea Gnat Chaff [Seduction] -
(1987) Decoy (Expendable) Surface Max: 1.9 km. |
| Mk186 TORCH Flare [Seduction] -
(1979) Decoy (Expendable) Surface Max: 1.9 km. |
| Stingray Mod 0 -
(1986) Torpedo Subsurface Max: 7.4 km. |
