General data: | |
---|---|
Type: FFL - Corvette | Max Speed: 35 kt |
Crew: 43 | Length: 72.7 m |
Beam: 10.4 m | Draft: 2.4 m |
Displacement Full: 640 t | Displacement: 500 t |
Operator: Navy | Commissioned: 2009 |
Propulsion: 2x MTU-Friedrichshafen 16V 2000 N90 Diesels, 4x Vericor TF50A Gas Turbines, CODOG, 125SII Kamewa Waterjets |
Sensors / EW: |
---|
CHMS-90 Hydra - (Visby) Hull Sonar, Active-Only Hull Sonar, Active-Only Shallow Water High-Definition Mine & Obstacle Avoidance Max Range: 1.1 km |
Pilot Mk.2 - (LPI) Radar Radar, Surface Search & Navigation Max Range: 88.9 km |
CVDS-26 Hydra - (Visby) VDS, Active/Passive Sonar VDS, Active/Passive Variable Depth Sonar Max Range: 27.8 km |
Hydra TASS - (Visby) TASS, Passive-Only Towed Array Sonar System TASS, Passive-Only Thin Line Towed Array Sonar System Max Range: 27.8 km |
ES-3701 Seawatch - (Visby) ESM ELINT w/ OTH Targeting Max Range: 926 km |
Sea Giraffe AMB 3D - (2005, AN/SPS-77(V)1) Radar Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface Max Range: 148.2 km |
EOS 500 [CCD] - (Group, 9GR400, Stealth Gunhouse) Visual LLTV, Weapon Director Max Range: 185.2 km |
EOS 500 [IR Camera] - (Group, 9GR400, Stealth Gunhouse) Infrared Infrared, Weapon Director Camera Max Range: 185.2 km |
EOS 500 [Laser Rangefinder] - (Group, 9GR400, Stealth Gunhouse) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 7.4 km |
CEROS 200 Tracker [9LV Mk3E CETRIS] - (Group, 9GR400, Stealth Gunhouse) Radar Radar, FCR, Weapon Director Max Range: 46.3 km |
Weapons: |
---|
DUAL TRAP Chaff/Flare -
Decoy (Expendable) Surface Max: 1.9 km. |
57mm/70 Bofors Mk3 GP Burst [4 rnds] -
Gun Air Max: 2.2 km. Surface Max: 9.3 km. Land Max: 9.3 km. |
