General data: | |
---|---|
Type: PCFG - Fast Guided Missile Patrol Craft | Max Speed: 40 kt |
Crew: 35 | Length: 45 m |
Beam: 7 m | Draft: 1.8 m |
Displacement Full: 250 t | Displacement: 220 t |
Operator: Navy | Commissioned: 1986 |
Propulsion: 4x MTU MD871 Diesels | Decommissioned: 1988 |
Sensors / EW: |
---|
THD 1040 Neptune - (TRS 3030) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 46.3 km |
EL/M-2221 [RTN-10X (Orion 10X)] - (1972, 76mm FCR) Radar Radar, FCR, Weapon Director Max Range: 37 km |
Galileo OG R7/2 - (Galileo OG 20) Visual Visual, Weapon Director TV Camera Max Range: 129.6 km |
Newton Alpha [ELT 211, ESM] - (Israeli MN-53) ESM ELINT Max Range: 926 km |
Newton Alpha [ELT 521, ECM] - (Israeli MN-53) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
Weapons: |
---|
76mm/62 Compact HE Burst [4 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
12.7mm/50 MG Burst [10 rnds] -
(Facility/Ship, No Anti-Air Capability) Gun Surface Max: 1.9 km. Land Max: 1.9 km. |
RGM-84D Harpoon IC -
(1986) Guided Weapon Surface Max: 138.9 km. |
Gabriel II -
(1977) Guided Weapon Surface Max: 51.9 km. |
SRCR Chaff -
(Israel, 90mm) Decoy (Expendable) Surface Max: 1.9 km. |
