General data:
Type: PCFG - Fast Guided Missile Patrol Craft Max Speed: 36 kt
Crew: 30 Length: 47 m
Beam: 7.1 m Draft: 2.1 m
Displacement Full: 265 t Displacement: 345 t
Operator: Navy Commissioned: 1991
Propulsion: 4x MTU MD16V 538 TB90 Diesels Decommissioned: 2002
Sensors / EW:
TRS 3050 Triton G - (1988, DRBV 52) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 46.3 km
Telegon 6 - (CXA(1)) ESM
HF/DF
Max Range: 926 km
3RM-20 - (AN/SPS-63) Radar
Radar, Surface Search, Short-Range
Max Range: 74.1 km
Scorpion - (AN/SPS-63) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
Cutlass B1 - (Assoc w Scorpion jammer/Anaren antenna) ESM
ELINT w/ OTH Targeting
Max Range: 926 km
TRS 3201 Castor II - (Crotale FCR) Radar
Radar, FCR, Surface-to-Air, Short-Range
Max Range: 29.6 km
Panda [Optical] - (Group) Visual
Visual, Weapon Director TV Camera
Max Range: 74.1 km
Weapons:
MM.38 Exocet Blk I - (1976) Guided Weapon
Surface Max: 42.6 km.
76mm/62 Compact HE Burst [4 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
12.7mm/50 MG Burst [10 rnds] - (Facility/Ship, No Anti-Air Capability) Gun
Surface Max: 1.9 km. Land Max: 1.9 km.
Hot Dog Flare - (76mm) Decoy (Expendable)
Surface Max: 1.9 km.
Silver Dog Chaff - (76mm) Decoy (Expendable)
Surface Max: 1.9 km.
40mm/70 Single Breda Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
