General data:
Type: FFL - Corvette Max Speed: 26 kt
Crew: 70 Length: 114.0 m
Beam: 16.0 m Draft: 5.0 m
Displacement Full: 0 t Displacement: 3900 t
Operator: Navy Commissioned: 2028
Propulsion: 4x MAN 12V 175D Diesels, 1x GE LM2500 Gas Turbine, CODLAG
Sensors / EW:
Sea Giraffe 4A - (AESA, GaN) Radar
Radar, Air & Surface Search, 3D Medium-Range
Max Range: 277.8 km
Sea Giraffe 1X - (2016, SHORAD) Radar
Radar, Air & Surface Search, 3D Short-Range
Max Range: 74.1 km
EOS 500 [CCD] - (Group, 9GR400) Visual
LLTV, Weapon Director
Max Range: 185.2 km
EOS 500 [IR Camera] - (Group, 9GR400) Infrared
Infrared, Weapon Director Camera
Max Range: 185.2 km
EOS 500 [Laser Rangefinder] - (Group, 9GR400) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
CEROS 200 Tracker [9LV Mk4 ESSM] - (Group, 9GR400) Radar
Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range
Max Range: 74.1 km
SS2030 - (Group, 9GR400) Hull Sonar, Active-Only
Hull Sonar, Active-Only Search
Max Range: 5.6 km
SD9500 - (Group, 9GR400) VDS, Active Only Sonar
VDS, Active-Only Variable Depth Sonar
Max Range: 1.5 km
C-Fire [Laser Rangefinder] - (Group, 9GR400) Laser Rangefinder
Laser Rangefinder
Max Range: 18.5 km
C-Fire [IR] - (Group, 9GR400) Infrared
Infrared, Weapon Director & Target Search, Tracking and Identification Camera
Max Range: 55.6 km
C-Fire [TV Camera] - (Group, 9GR400) Visual
Visual, Weapon Director & Target Search, Tracking and Identification TV Camera
Max Range: 55.6 km
Generic ESM [Advanced] - (2010s, Precise Emitter ID) ESM
ELINT
Max Range: 926 km
Generic COMINT - (2010s) ESM
COMINT
Max Range: 926 km
Generic DECM [Advanced] - (2010s) ECM
DECM, Defensive ECM
Max Range: 0 km
NLWS Naval Laser Warning System - (2010s) ESM
LWR, Laser Warning Receiver
Max Range: 11.1 km
Weapons:
57mm/70 Bofors Mk3 GP Burst [4 rnds] - Gun
Air Max: 2.2 km. Surface Max: 9.3 km. Land Max: 9.3 km.
Gabriel V - (2010) Guided Weapon
Surface Max: 200 km. Land Max: 200 km.
RIM-162B ESSM - (2004, non-AEGIS, Mk41) Guided Weapon
Air Max: 55.6 km. Surface Max: 46.3 km.
12.7mm/50 MG Burst [10 rnds] - (Facility/Ship, No Anti-Air Capability) Gun
Surface Max: 1.9 km. Land Max: 1.9 km.
Saab Lightweight Torpedo - (2020, SLWT, Torped 47) Torpedo
Subsurface Max: 20 km.
DUAL TRAP Chaff/Flare - Decoy (Expendable)
Surface Max: 1.9 km.
Mine [PM04] - (Finland, Sea Mine 2000) Bottom Mine
Mine [PM16] - (Finland) Bottom Mine
