| General data: | |
|---|---|
| Type: CV - Aircraft Carrier | Max Speed: 30 kt |
| Crew: 1700 | Length: 304.5 m |
| Beam: 40 m | Draft: 5.1 m |
| Displacement Full: 67500 t | Displacement: 45900 t |
| Operator: Navy | Commissioned: 2015 |
| Propulsion: 8x KVG-4 Boilers, 4x TV12-4 Geared Steam Turbines |
| Sensors / EW: |
|---|
| Strut Pair 2 [MR-320 Topaz] - (2x Strut Curve antennas) Radar Radar, Air & Surface Search, 2D Medium-Range Max Range: 277.8 km |
| Flat Track [MRP-15] - (2x Strut Curve antennas) ESM ELINT Max Range: 926 km |
| Tin Man - (2x Strut Curve antennas) Visual Visual, Surveillance TV Camera Max Range: 55.6 km |
| Wine Glass [MP-407] - (Ex-Football B, Assoc w Half Hat or Bell Bash) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
| Wine Flask [MP-405] - (Ex-Football B, Assoc w Half Hat or Bell Bash) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
| Bell Thump - (Assoc w Wine Flask, Wine Glass) ESM ELINT Max Range: 926 km |
| Bell Bash - (Assoc w Wine Flask, Wine Glass) ESM ELINT Max Range: 926 km |
| Bell Push - (Assoc w Wine Flask, Wine Glass) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
| Bull Nose [MGK-335M Platina] - (1981, Assoc w Mare Tail & Steer Hide) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search Max Range: 27.8 km |
| Cross Swords [Radar] - (Group) Radar Radar, FCR, Surface-to-Air, Short-Range Max Range: 22.2 km |
| Cross Swords [TV Camera] - (Group) Visual Visual, Target Tracking and Identification TV Camera Max Range: 148.2 km |
| Top Plate [MR-750 Fregat MA] - (Group) Radar Radar, Air & Surface Search, 3D Long-Range Max Range: 296.3 km |
| Palm Frond [MR-210 Vaigath] - (Group) Radar Radar, Surface Search & Navigation Max Range: 46.3 km |
| MR-350 Podkat - (Low-Alt SSM Warning) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 33.3 km |
| Weapons: |
|---|
| PK-10 Chaff [SR-50] -
(1990, 120mm) Decoy (Expendable) Surface Max: 1.9 km. |
| PK-10 Flare [SO-50] -
(1990, 120mm) Decoy (Expendable) Surface Max: 1.9 km. |
| PK-2 Chaff [TSP-47] -
(1970, 140mm) Decoy (Expendable) Surface Max: 1.9 km. |
| PK-2 Flare [TST-47] -
(1970, 140mm) Decoy (Expendable) Surface Max: 1.9 km. |
| SS-N-19 Shipwreck [P-700 Granit] -
(1984) Guided Weapon Surface Max: 555.6 km. |
| RBU-12000 Torpedo Decoy Salvo [UDAV-1, 10 rnds] -
(1987, 111SO) Decoy (Expendable) Surface Max: 1.9 km. |
| RBU-12000 Anti-Torpedo Depth Charge Salvo [UDAV-1, 10 rnds] -
(1987) Depth Charge Subsurface Max: 1.9 km. |
| 30mm Twin Gatling Gsh-6-30K Burst [375 rnds] -
(CADS-N-1) Gun Air Max: 1.9 km. Surface Max: 2.8 km. |
| SA-N-11a Grisom [9M311K] -
(1988, Kashtan, 3M87 Kortik) Guided Weapon Air Max: 7.4 km. Surface Max: 7.4 km. |
| SA-N-9 Gauntlet [9M330-2 Kinzhal] -
Guided Weapon Air Max: 16.7 km. Surface Max: 16.7 km. |
| AK-630M 30mm/65 Gatling Burst [400 rnds] -
Gun Air Max: 1.9 km. Surface Max: 2.8 km. |
