| General data: | |
|---|---|
| Type: FF - Frigate | Max Speed: 32 kt |
| Crew: 163 | Length: 117.5 m |
| Beam: 14.8 m | Draft: 6 m |
| Displacement Full: 3600 t | Displacement: 3300 t |
| Operator: Navy | Commissioned: 2011 |
| Propulsion: 2x MTU 12V 1163 TB83 Diesels, 1x General Electric LM-2500-30 Gas Turbine, CODOG |
| Sensors / EW: |
|---|
| Sceptre XL - (Manta) ESM ELINT Max Range: 926 km |
| Telegon 10 - (PGS 1720) ESM HF/DF Max Range: 926 km |
| AN/SPS-49(V)8 - (PGS 1720) Radar Radar, Air Search, 2D Long-Range Max Range: 463 km |
| Atlas 9600-M ARPA - (PGS 1720) Radar Radar, Surface Search & Navigation Max Range: 46.3 km |
| Sea Giraffe 150 HC - (1990, CA/SPS-505, PS 76) Radar Radar, Target Indicator, 3D Surface-to-Air Max Range: 100 km |
| CEROS 200 Tracker [9LV Mk3 CWI] - (Group, 9GR400) Radar Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range Max Range: 46.3 km |
| EOS 500 [CCD] - (Group, 9GR400) Visual LLTV, Weapon Director Max Range: 185.2 km |
| EOS 500 [IR Camera] - (Group, 9GR400) Infrared Infrared, Weapon Director Camera Max Range: 185.2 km |
| EOS 500 [Laser Rangefinder] - (Group, 9GR400) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 7.4 km |
| TSM 2633 Spherion B Mk2 - (Group, 9GR400) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 14.8 km |
| Radamec 2400 [EO] - (Group, 9GR400) Visual Visual, Weapon Director & Target Search, Tracking and Identification TV Camera Max Range: 55.6 km |
| Radamec 2400 [IR] - (Group, 9GR400) Infrared Infrared, Weapon Director & Target Search, Tracking and Identification Camera Max Range: 55.6 km |
| Radamec 2400 [Laser Rangefinder] - (Group, 9GR400) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 7.4 km |
| Weapons: |
|---|
| 12.7mm/50 Mini-Typhoon Burst [10 rnds] -
Gun Surface Max: 1.9 km. Land Max: 1.9 km. |
| 127mm/54 HE-CVT [HiFrag] -
(USN) Gun Air Max: 2.8 km. Surface Max: 20.4 km. Land Max: 20.4 km. |
| 127mm/54 HE-PD [HiCap] -
(USN) Gun Air Max: 2.8 km. Surface Max: 20.4 km. Land Max: 20.4 km. |
| Mk46 LWT Mod 2 -
(1972) Torpedo Subsurface Max: 5.6 km. |
| Mk214 Sea Gnat Chaff [Seduction] -
(1987) Decoy (Expendable) Surface Max: 1.9 km. |
| Mk216 Sea Gnat Chaff [Distraction] -
(1988) Decoy (Expendable) Surface Max: 1.9 km. |
| DM19A2 Flare [Mk245 GIANT] -
Decoy (Expendable) Surface Max: 1.9 km. |
| RIM-7P Sea Sparrow -
(1994) Guided Weapon Air Max: 25.9 km. Surface Max: 25.9 km. |
| AN/SLQ-25A Nixie -
Decoy (Towed) Surface Max: 1.9 km. |
| 20mm/100 Mk15 Phalanx Blk 1B Burst [300 rnds] -
Gun Air Max: 1.5 km. Surface Max: 1.9 km. |
