General data: | |
---|---|
Type: PCF - Fast Patrol Craft | Max Speed: 30 kt |
Crew: 28 | Length: 49.5 m |
Beam: 9.2 m | Draft: 2.5 m |
Displacement Full: 365 t | Displacement: 333 t |
Operator: Navy | Commissioned: 2003 |
Propulsion: 3x MTU-4000 Diesels |
Sensors / EW: |
---|
Furuno FR-2150W - Radar Radar, Surface Search & Navigation Max Range: 177.8 km |
Bass Tilt [Radar] - (Group, 30mm GFCR, Pair of guns) Radar Radar, FCR, Surface-to-Air, Short-Range Max Range: 22.2 km |
Bass Tilt [Laser Rangefinder] - (Group, 30mm GFCR, Pair of guns) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 9.3 km |
Bass Tilt [TV Camera] - (Group, 30mm GFCR, Pair of guns) Visual Visual, Weapon Director TV Camera Max Range: 74.1 km |
Lamb Tail [MG-349M Ros-K] - (Ship) VDS, Active/Passive Sonar VDS, Active/Passive Variable Depth Sonar Max Range: 5.6 km |
Weapons: |
---|
AK-176 76mm/60 HE Burst [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
AK-176 76mm/60 Frag Burst [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
AK-630 30mm/65 Gatling Burst [400 rnds] -
Gun Air Max: 1.9 km. Surface Max: 2.8 km. |
SA-N-5 Grail [9M32M] -
(9K32M Strela-2M, MANPADS) Guided Weapon Air Max: 3.7 km. |
