General data: | |
---|---|
Type: OPV - Offshore Patrol Vessel | Max Speed: 20 kt |
Crew: 85 | Length: 105.7 m |
Beam: 15.2 m | Draft: 4.7 m |
Displacement Full: 0 t | Displacement: 3800 t |
Operator: Navy | Commissioned: 2009 |
Propulsion: 4x Nohab-Polar F212-D825 Diesels |
Sensors / EW: |
---|
PN-619 [Scanter] - (Scanter 009?) Radar Radar, Surface Search & Navigation Max Range: 46.3 km |
PS-751 & PS 726 [Sea Giraffe 50 HC & ArtE 726E Surveillance] - (1984) Radar Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface Max Range: 55.6 km |
9LV200 Mk2 [Radar] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Radar Radar, FCR, Weapon Director Max Range: 14.8 km |
9LV200 Mk2 [TV Camera] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Visual Visual, Weapon Director TV Camera Max Range: 148.2 km |
9LV200 Mk2 [IR] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Infrared Infrared, Weapon Director Camera Max Range: 148.2 km |
9LV200 Mk2 [Laser Rangefinder] - (Group, PE 727 Radar, 9LV223, 225, 228, 249, ArtE-726) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 7.4 km |
PQ-868 [AR-700 Phoenix I] - (1984, ASP-32, Assoc w PQ 844) ESM ELINT Max Range: 926 km |
Weapons: |
---|
57mm/70 Bofors Mk1 HCER Burst [4 rnds] -
Gun Surface Max: 8.3 km. Land Max: 8.3 km. |
57mm/70 Bofors Mk1 HE Burst [4 rnds] -
Gun Air Max: 2.2 km. Surface Max: 8.3 km. Land Max: 8.3 km. |
40mm/70 m/48 Single Bofors Burst [4 rnds] -
Gun Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km. |
12.7mm/50 MG Burst [10 rnds] -
(Facility/Ship, No Anti-Air Capability) Gun Surface Max: 1.9 km. Land Max: 1.9 km. |
7.62mm MG Burst [20 rnds] -
(Ship & Facility) Gun Surface Max: 0.4 km. Land Max: 0.4 km. |
Philax Chaff -
Decoy (Expendable) Surface Max: 1.9 km. |
