| General data: | |
|---|---|
| Type: LSD - Dock Landing Ship | Max Speed: 22 kt |
| Crew: 374 | Length: 169.0 m |
| Beam: 26.0 m | Draft: 6.1 m |
| Displacement Full: 14225 t | Displacement: 10000 t |
| Operator: Navy | Commissioned: 1999 |
| Propulsion: 2x Boilers, 2x Steam Turbines |
| Sensors / EW: |
|---|
| AN/SLQ-32(V)1 [RWR] - (Group, 1980) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| AN/SPS-10B - (Group, 1980) Radar Radar, Surface Search & Navigation Max Range: 74.1 km |
| AN/SPS-40 - (1963) Radar Radar, Air Search, 2D Long-Range Max Range: 407.4 km |
| AN/SPS-64(V)9 [RM 1220 6X] - (20kW, USN, 1x antenna) Radar Radar, Surface Search & Navigation Max Range: 37 km |
| Weapons: |
|---|
| 20mm/85 Mk15 Phalanx Blk 0 Burst [200 rnds] -
Gun Air Max: 1.5 km. |
| 12.7mm/50 MG Burst [10 rnds] -
(Facility/Ship, No Anti-Air Capability) Gun Surface Max: 1.9 km. Land Max: 1.9 km. |
| Mk182 SRBOC Chaff [Seduction] -
(1979) Decoy (Expendable) Surface Max: 1.9 km. |
| Mk186 TORCH Flare [Seduction] -
(1979) Decoy (Expendable) Surface Max: 1.9 km. |
| AN/SLQ-25 Nixie -
Decoy (Towed) Surface Max: 1.9 km. |
