| General data: | |
|---|---|
| Type: FFG - Guided Missile Frigate | Max Speed: 30 kt |
| Crew: 232 | Length: 122.7 m |
| Beam: 12.9 m | Draft: 4.2 m |
| Displacement Full: 3060 t | Displacement: 2700 t |
| Operator: Navy | Commissioned: 1982 |
| Propulsion: 2x Wärtsilä NSD B230-20DVM Diesels, 2x General Electric-Fiat LM-2500 Gas Turbines, CODOG |
| Sensors / EW: |
|---|
| Telegon 4 - (AK 1200) ESM HF/DF Max Range: 926 km |
| DE 1163 VDS [DE 1164 Integrated Suite] - (DE 1160 Hull + DE 1163 VDS) VDS, Active/Passive Sonar VDS, Active/Passive Variable Depth Sonar Max Range: 9.3 km |
| DE 1160B [DE 1164 Integrated Suite] - (DE 1160 Hull + DE 1163 VDS) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 9.3 km |
| MM/SPN-703 - (3RM-20B) Radar Radar, Surface Search, Short-Range Max Range: 74.1 km |
| MM/SPS-774 [RAN-10S Pluto] - (NA-30B/E Search) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 166.7 km |
| Galileo OG 30 [FLIR] - (Gun Control) Infrared Infrared, Weapon Director & Target Tracking and Identification Camera Max Range: 185.2 km |
| Galileo OG 30 [TV] - (Gun Control) Visual Visual, Weapon Director & Target Tracking and Identification TV Camera Max Range: 185.2 km |
| Galileo OG 30 [Laser Rangefinder] - (Gun Control) Laser Rangefinder Laser Rangefinder for Weapon Director / Target Tracking and Identification Max Range: 0 km |
| MM/SPG-76 [Radar] - (RTN-30X, Aspide) Radar Radar Illuminator, Medium-Range Max Range: 46.3 km |
| MM/SPS-702 - (1986, SPQ-702?) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 74.1 km |
| MM/SPG-74 Dardo [Radar] - (RTN-20X, Gun) Radar Radar, FCR, Weapon Director Max Range: 13 km |
| MM/SPG-74 Dardo [TV Camera] - (Gun-Only) Visual Visual, Weapon Director TV Camera Max Range: 74.1 km |
| Galileo OG R7/2 - (Galileo OG 20) Visual Visual, Weapon Director TV Camera Max Range: 129.6 km |
| MM/SLR-4 Newton Lambda [ELT 311] - (Lupo) ESM ELINT Max Range: 926 km |
| MM/SLQ-D Newton Lambda [ELT 318/521] - (Lupo) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
| Weapons: |
|---|
| Aspide -
(1980, SAM) Guided Weapon Air Max: 18.5 km. Surface Max: 18.5 km. |
| 20mm/70 Oerlikon Mk7 Burst [20 rnds] -
Gun Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km. |
| 40mm/70 Twin Breda Compact Burst [32 rnds] -
Gun Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km. |
| 127mm/54 OTO Melara Compact HECVT -
Gun Air Max: 2.8 km. Surface Max: 20.4 km. Land Max: 20.4 km. |
| 127mm/54 OTO Melara Compact HiCap -
Gun Air Max: 2.8 km. Surface Max: 20.4 km. Land Max: 20.4 km. |
| A.184 Mod 1 -
(1975, Ship) Torpedo Subsurface Max: 7.4 km. |
| Mk46 LWT Mod 2 -
(1972) Torpedo Subsurface Max: 5.6 km. |
| SCLAR Chaff -
Decoy (Expendable) Surface Max: 1.9 km. |
| SCLAR Flare -
Decoy (Expendable) Surface Max: 1.9 km. |
| AN/SLQ-25 Nixie -
Decoy (Towed) Surface Max: 1.9 km. |
| Otomat Mk2 Mod I -
(1980) Guided Weapon Surface Max: 185.2 km. |
