| General data: | |
|---|---|
| Type: FFG - Guided Missile Frigate | Max Speed: 29 kt |
| Crew: 170 | Length: 123.2 m |
| Beam: 13.8 m | Draft: 3.76 m |
| Displacement Full: 3144 t | Displacement: 2500 t |
| Operator: Navy | Commissioned: 2010 |
| Propulsion: 4x 18E390VA Diesels, CODAD |
| Sensors / EW: |
|---|
| Crotale TV Tracker - (Group, Crotale FCR, Castor IIJ?) Visual Visual, Target Tracking and Identification TV Camera Max Range: 74.1 km |
| China Type 345 [Radar] - (Crotale) Radar Radar, FCR, Surface-to-Air, Short-Range Max Range: 29.6 km |
| Piranha [IR] - (Castor IIJ) Infrared Infrared, Target Tracking and Identification Camera Max Range: 148.2 km |
| China Type 347 Rice Bowl - (GFCR, 100mm, EFR-1) Radar Radar, FCR, Weapon Director Max Range: 37 km |
| Decca 1290 Master - (GFCR, 100mm, EFR-1) Radar Radar, Surface Search & Navigation Max Range: 37 km |
| China Type 981 [Newton Beta] - (NRJ-5, NJ-81, RWD-8,) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
| China Type 517 Knife Rest - (Pea Sticks) Radar Radar, Air Search, 2D Medium-Range Max Range: 203.7 km |
| China Type 363 - (MR-36?) Radar Radar, Target Indicator, 2D Surface-to-Air Max Range: 129.6 km |
| China Type 360 - (Sea Tiger, MR-36A(?), SR-60, S-3, Seagull-S) Radar Radar, Air & Surface Search, 2D Medium-Range Max Range: 250 km |
| China Type 825 - (Assoc with Type 981 Jammer) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| China H/SJD-4 - (Luda I, SJD-N Replacement) Hull Sonar, Active-Only Hull Sonar, Active-Only Mortar Fire Control Max Range: 3.7 km |
| Weapons: |
|---|
| China Type 65 ASW Rocket Salvo [6 rnds] -
Rocket Subsurface Max: 1.9 km. |
| 100mm/56 Twin PJ33A Frag Burst [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
| 100mm/56 Twin PJ33A HE [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
| HQ-7 Crotale [FM-80] Naval -
(China, 1990, CSA-4) Guided Weapon Air Max: 9.3 km. Surface Max: 9.3 km. |
| 30mm China H/PJ-12 [Type 730, 240 rnds] -
(China, Goalkeeper Copy) Gun Air Max: 1.9 km. Surface Max: 2.8 km. |
| C-802 -
(1995, Iranian Noor 2, Not Adopted by China) Guided Weapon Surface Max: 129.6 km. |
| Generic Chaff Rocket -
(Ship-only) Decoy (Expendable) Surface Max: 1.9 km. |
| Yu-7 -
(China, 1998?) Torpedo Subsurface Max: 3.7 km. |
