General data: | |
---|---|
Type: DDG - Guided Missile Destroyer | Max Speed: 28 kt |
Crew: 202 | Length: 147.2 m |
Beam: 18.6 m | Draft: 5.2 m |
Displacement Full: 7700 t | Displacement: 6890 t |
Operator: Navy | Commissioned: 2017 |
Propulsion: 2x Bravo 16V Diesels, 2x General Electric LM-2500-SA-MLG38 Gas Turbines, CODOG |
Sensors / EW: |
---|
AN/SPY-1D(V) MFR [ABM Mod] - Radar Radar, FCR, Surface-to-Air, Long-Range Max Range: 324.1 km |
AN/SPG-62 [Mk99 FCS, ABM Mod] - Radar Radar Illuminator, Long-Range Max Range: 305.6 km |
AN/SPQ-9B - (2001) Radar Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface Max Range: 46.3 km |
Generic Surface Search Radar - (96nm) Radar Radar, Surface Search, Medium-Range Max Range: 177.8 km |
Radamec 2500 [EO] - (96nm) Visual Visual, Weapon Director & Target Search, Tracking and Identification TV Camera Max Range: 55.6 km |
Radamec 2500 [IR] - (96nm) Infrared Infrared, Weapon Director & Target Search, Tracking and Identification Camera Max Range: 55.6 km |
Radamec 2500 [Laser Rangefinder] - (96nm) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 7.4 km |
C-Lite [IR] - (Group, 2001, Toplite) Infrared Infrared, Weapon Director Camera Max Range: 185.2 km |
C-Lite [Optronics] - (Group, 2001, Toplite) Visual Visual, Weapon Director TV Camera Max Range: 185.2 km |
C-Lite [Laser Rangefinder] - (Group, 2001, Toplite) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 0 km |
VAMPIR-MB [CCD] - (Group, 1996, Detector) Visual LLTV, Target Search, Slaved Tracking and Identification Max Range: 148.2 km |
VAMPIR-MB [IR] - (Group, 1996, Detector) Infrared Infrared, Target Search, Slaved Tracking and Identification Camera Max Range: 148.2 km |
VAMPIR-MB [Laser Rangefinder] - (Group, 1996, Detector) Laser Rangefinder Laser Rangefinder Max Range: 0 km |
ES-3701 Seawatch - (Group, 1996, Detector) ESM ELINT w/ OTH Targeting Max Range: 926 km |
MMVDS Hull - (Modular Multistatic Variable Depth Sonar System) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 74.1 km |
MMVDS TASS - (Modular Multistatic Variable Depth Sonar System) TASS, Passive-Only Towed Array Sonar System TASS, Passive-Only Towed Array Sonar System Max Range: 129.6 km |
MMVDS VDS - (LFAPS-D(?)) VDS, Active/Passive Sonar VDS, Active/Passive Variable Depth Sonar Max Range: 44.4 km |
Weapons: |
---|
25mm/75 Typhoon Burst [10 rnds] -
Gun Air Max: 1.5 km. Surface Max: 2.8 km. Land Max: 2.8 km. |
127mm/62 HE-CVT [HiFrag] -
Gun Air Max: 2.8 km. Surface Max: 22.2 km. Land Max: 24.1 km. |
127mm/62 HE-PD [HiCap] -
Gun Air Max: 2.8 km. Surface Max: 22.2 km. Land Max: 24.1 km. |
127mm/62 WP -
Gun Surface Max: 22.2 km. Land Max: 24.1 km. |
RGM-84L Harpoon II -
(2003) Guided Weapon Surface Max: 138.9 km. Land Max: 138.9 km. |
LRCR Chaff -
(179mm, Israel) Decoy (Expendable) Surface Max: 1.9 km. |
PIRATE Flare -
Decoy (Expendable) Surface Max: 1.9 km. |
RIM-162A ESSM -
(2004, AEGIS, Mk41) Guided Weapon Air Max: 55.6 km. Surface Max: 46.3 km. |
RIM-66M-5 SM-2MR Blk IIIB -
(2000, AEGIS VLS) Guided Weapon Air Max: 166.7 km. Surface Max: 46.3 km. |
AN/SLQ-25 Nixie -
Decoy (Towed) Surface Max: 1.9 km. |
MU-90 Impact -
(2003, Ex-Murene, Ex-A.290) Torpedo Subsurface Max: 7.4 km. |
Mk234 Nulka -
(2002) Decoy (Expendable) Surface Max: 1.9 km. |
20mm/100 Mk15 Phalanx Blk 1B Burst [300 rnds] -
Gun Air Max: 1.5 km. Surface Max: 1.9 km. |
