General data: | |
---|---|
Type: MCM - Mine Countermeasures Ship | Max Speed: 16 kt |
Crew: 68 | Length: 61 m |
Beam: 10.2 m | Draft: 3 m |
Displacement Full: 804 t | Displacement: 750 t |
Operator: Navy | Commissioned: 1992 |
Propulsion: 2x M-503B-37 Diesels |
Sensors / EW: |
---|
Bell Tap - ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
Drum Tilt [MR-104 Rys] - (25mm & 30mm GFCR) Radar Radar, FCR, Weapon Director Max Range: 22.2 km |
Don 2 - (25mm & 30mm GFCR) Radar Radar, Surface Search & Navigation Max Range: 46.3 km |
Mine Avoidance [MG-69 Lan-2] - (1966, Minesweeper) Hull Sonar, Active-Only Hull Sonar, Active-Only Mine Avoidance Max Range: 0.9 km |
Generic Mechanical Cable Cutter Mine Sweep - (1966, Minesweeper) Mine Sweep, Mechanical Cable Cutter Mine Sweep, Mechanical Cable Cutter Max Range: 0 km |
Generic Mine Disposal Diver - (80m depth) Mine Neutralization, Diver-deployed Explosive Charge Mine Neutralization, Diver-deployed Explosive Charge Max Range: 0 km |
Generic Magnetic & Acoustic Mine Sweep - (80m depth) Mine Sweep, Magnetic & Acoustic Multi-Influence Mine Sweep, Magnetic & Acoustic Multi-Influence Max Range: 0 km |
Weapons: |
---|
AK-230 30mm/65 Twin Burst [50 rnds] -
Gun Air Max: 1.9 km. Surface Max: 2.8 km. |
25mm/80 Twin Burst [20 rnds] -
Gun Air Max: 1.5 km. Surface Max: 2.8 km. Land Max: 2.8 km. |
SA-N-5 Grail [9M32M] -
(9K32M Strela-2M, MANPADS) Guided Weapon Air Max: 3.7 km. |
RSL-12 ASW Rocket Salvo [5 rnds] -
(1963, RBU-1200) Rocket Subsurface Max: 1.9 km. |
