General data:
Type: DDG - Guided Missile Destroyer Max Speed: 31 kt
Crew: 266 Length: 144 m
Beam: 16 m Draft: 5.1 m
Displacement Full: 4800 t Displacement: 4200 t
Operator: PLAN Commissioned: 1999
Propulsion: 2x MTU 12V 1163 TB83 Diesels, 2x GE LM-2500 Gas Turbines, CODOG
Sensors / EW:
Decca 1290 Master - Radar
Radar, Surface Search & Navigation
Max Range: 37 km
DRBV 15 Sea Tiger [TRS 3001] - Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 133.3 km
China Type 362 - (Type 347S, ESR-1, SR-47A, MR-36) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 120.4 km
China Type 518 Sea Eye - (Hai Ying, REL-1) Radar
Radar, Air Search, 2D Medium-Range
Max Range: 277.8 km
Crotale TV Tracker - (Group, Crotale FCR, Castor IIJ?) Visual
Visual, Target Tracking and Identification TV Camera
Max Range: 74.1 km
China Type 345 [Radar] - (Crotale) Radar
Radar, FCR, Surface-to-Air, Short-Range
Max Range: 29.6 km
Piranha [IR] - (Castor IIJ) Infrared
Infrared, Target Tracking and Identification Camera
Max Range: 148.2 km
DE 1160B [DE 1164 Integrated Suite] - (DE 1160 Hull + DE 1163 VDS) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 9.3 km
DE 1163 VDS [DE 1164 Integrated Suite] - (DE 1160 Hull + DE 1163 VDS) VDS, Active/Passive Sonar
VDS, Active/Passive Variable Depth Sonar
Max Range: 9.3 km
Rapids [Improved Sphinx] - (DE 1160 Hull + DE 1163 VDS) ESM
ELINT
Max Range: 926 km
China Type 984-1 [ECM] - (RAMSES Copy) ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
China Type 984-1 [RWR] - (RAMSES Copy) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
China Type 344 - (GFCR, 100/130mm, MR-34) Radar
Radar, FCR, Weapon Director
Max Range: 27.8 km
China Type 347G Rice Bowl - (37mm, EFR-1) Radar
Radar, FCR, Weapon Director
Max Range: 37 km
Weapons:
100mm/56 Twin PJ33A Frag Burst [2 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
100mm/56 Twin PJ33A HE [2 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
37mm/63 Twin Burst [20 rnds] - Gun
Air Max: 1.9 km. Surface Max: 2.8 km.
HQ-7 Crotale [FM-80] Naval - (China, 1990, CSA-4) Guided Weapon
Air Max: 9.3 km. Surface Max: 9.3 km.
YJ-8A [C-801A] - (China, 1993) Guided Weapon
Surface Max: 46.3 km.
Yu-7 - (China, 1998?) Torpedo
Subsurface Max: 3.7 km.
FQF-2500 Anti-Torpedo Depth Charge Salvo [12 rnds] - Depth Charge
Subsurface Max: 1.9 km.
Generic Chaff Rocket - (Ship-only) Decoy (Expendable)
Surface Max: 1.9 km.
Mk182 SRBOC Chaff [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
Mk186 TORCH Flare [Seduction] - (1979) Decoy (Expendable)
Surface Max: 1.9 km.
