| General data: | |
|---|---|
| Type: FFG - Guided Missile Frigate | Max Speed: 27 kt |
| Crew: 353 | Length: 126.4 m |
| Beam: 14.5 m | Draft: 4.5 m |
| Displacement Full: 4450 t | Displacement: 3850 t |
| Operator: Navy | Commissioned: 2004 |
| Propulsion: 2x Babcock & Wilcox Boilers, 2x Steam Turbines |
| Sensors / EW: |
|---|
| LW.08 - (RAWL-2, LAR-2, Type 1022, SPQ-502) Radar Radar, Air Search, 2D Long-Range Max Range: 333.4 km |
| ZW.06 - (1972, PIN 515) Radar Radar, Surface Search & Navigation Max Range: 46.3 km |
| Type 162M Cockshafer - (1972, PIN 515) Hull Sonar, Active-Only Hull Sonar, Active-Only Bottom Profiler Max Range: 1.3 km |
| Oceanic - (India) VDS, Active Only Sonar VDS, Active-Only Variable Depth Sonar Max Range: 9.3 km |
| HUS-001 APSOH - (Type 184 Derivative) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search Max Range: 9.3 km |
| EL/M-2221-GM STGR - (Barak FCR) Radar Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface Max Range: 111.1 km |
| RAN-1010 MBAT [SEWS] - (Rafael, RAN-1101, 1110 or Shark system) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
| EL/M-2238S 3D-STAR - (Large Antenna) Radar Radar, Air Search, 3D Long-Range Max Range: 351.9 km |
| PIN 521 APARNA [Garpun-Bal] - (India) Radar Radar, Surface Search w/ OTH Max Range: 140.8 km |
| Shikari TMX [Radar] - (Group, Seaguard TMX, 76mm FCR) Radar Radar, FCR, Weapon Director Max Range: 74.1 km |
| Shikari TMX [IR] - (Group, Seaguard TMX, 76mm FCR) Infrared Infrared, Weapon Director Camera Max Range: 148.2 km |
| Shikari TMX [Laser Rangefinder] - (Group, Seaguard TMX, 76mm FCR) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 0 km |
| C-Pearl - (Group, Seaguard TMX, 76mm FCR) ESM ELINT w/ OTH Targeting Max Range: 926 km |
| Weapons: |
|---|
| SS-N-25 Switchblade [Kh-35 Uran] GLONASS -
Guided Weapon Surface Max: 148.2 km. |
| AK-630 30mm/65 Gatling Burst [400 rnds] -
Gun Air Max: 1.9 km. Surface Max: 2.8 km. |
| 76mm/62 Compact HE Burst [4 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
| Barak 1 -
(1997) Guided Weapon Air Max: 11.1 km. |
| LRCR Chaff -
(179mm, Israel) Decoy (Expendable) Surface Max: 1.9 km. |
| A.244S -
(1986, NST58) Torpedo Subsurface Max: 5.6 km. |
| G738 [Type 182] Towed Torpedo Decoy -
Decoy (Towed) Surface Max: 1.9 km. |
| SRCR Chaff -
(Israel, 90mm) Decoy (Expendable) Surface Max: 1.9 km. |
