| General data: | |
|---|---|
| Type: FFG - Guided Missile Frigate | Max Speed: 26 kt |
| Crew: 200 | Length: 103.2 m |
| Beam: 10.8 m | Draft: 3.1 m |
| Displacement Full: 1960 t | Displacement: 1565 t |
| Operator: PLAN | Commissioned: 1975 |
| Propulsion: 2x 16PA 6V 280 BTC Diesels | Decommissioned: 1994 |
| Sensors / EW: |
|---|
| Generic TV Camera - (2nd Gen, Target Tracking And Identification) Visual Visual, Target Tracking and Identification TV Camera Max Range: 148.2 km |
| China Type 342 Fog Lamp [Radar] - (2nd Gen, Target Tracking And Identification) Radar Radar, FCR, Surface-to-Air, Short-Range Max Range: 29.6 km |
| China Type 923-1 Jug Pair - (RW-23-1, Watch Dog) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| China Type 343 Sun Visor [Radar] - (Group, 100mm FCS, Sun Visor / Wasp Head) Radar Radar, FCR, Weapon Director Max Range: 27.8 km |
| China Type 343 Wasp Head [Visual Director] - (Group, 100mm FCS, Sun Visor / Wasp Head) Visual Visual, Weapon Director TV Camera Max Range: 74.1 km |
| China Type 381A Rice Screen - (Sea Eagle) Radar Radar, Air & Surface Search, 3D Short-Range Max Range: 100 km |
| China Type 341 Rice Lamp - (37mm) Radar Radar, FCR, Weapon Director Max Range: 37 km |
| China H/SJD-2 - (Luda I) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search Max Range: 3.7 km |
| China Type 756 Fin Curve Mod [Decca 1229 Copy] - (Luda I) Radar Radar, Surface Search & Navigation Max Range: 46.3 km |
| China Type 352 Square Tie - (SSM, Rangout) Radar Radar, FCR, Surface-to-Surface Max Range: 74.1 km |
| Weapons: |
|---|
| HQ-61B -
(China, 1987, Naval) Guided Weapon Air Max: 18.5 km. Surface Max: 18.5 km. |
| Generic GMTR [Guided Missile Training Round] -
(Aka Drill Round) Training Round |
| Depth Charge [Generic] -
Depth Charge Subsurface Max: 0.2 km. |
| China Type 65 ASW Rocket Salvo [6 rnds] -
Rocket Subsurface Max: 1.9 km. |
| 100mm/56 Twin PJ33A Frag Burst [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
| 100mm/56 Twin PJ33A HE [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
| 37mm/63 Twin Burst [20 rnds] -
Gun Air Max: 1.9 km. Surface Max: 2.8 km. |
