| General data: | |
|---|---|
| Type: DDG - Guided Missile Destroyer | Max Speed: 31 kt |
| Crew: 230 | Length: 148.0 m |
| Beam: 15.6 m | Draft: 7.5 m |
| Displacement Full: 5700 t | Displacement: 4800 t |
| Operator: Navy | Commissioned: 2003 |
| Propulsion: 2x MTU 12V 1163 TB83 Diesels, 2x General Electric LM-2500 Gas Turbines, CODOG |
| Sensors / EW: |
|---|
| Crotale TV Tracker - (Group, Crotale FCR, Castor IIJ?) Visual Visual, Target Tracking and Identification TV Camera Max Range: 74.1 km |
| China Type 345 [Radar] - (Crotale) Radar Radar, FCR, Surface-to-Air, Short-Range Max Range: 29.6 km |
| Piranha [IR] - (Castor IIJ) Infrared Infrared, Target Tracking and Identification Camera Max Range: 148.2 km |
| China Type 344 - (GFCR, 100mm, MR-34) Radar Radar, FCR, Weapon Director Max Range: 27.8 km |
| DRBV 15 Sea Tiger [TRS 3001] - (GFCR, 100mm, MR-34) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 133.3 km |
| China Type 341 Rice Lamp - (37mm) Radar Radar, FCR, Weapon Director Max Range: 37 km |
| DE 1160B [DE 1164 Integrated Suite] - (DE 1160 Hull + DE 1163 VDS) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 9.3 km |
| DE 1163 VDS [DE 1164 Integrated Suite] - (DE 1160 Hull + DE 1163 VDS) VDS, Active/Passive Sonar VDS, Active/Passive Variable Depth Sonar Max Range: 9.3 km |
| China Type 362 - (ESR-1, SR-47A, MR-36A?) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 120.4 km |
| China Type 518 Sea Eye - (Hai Ying, REL-1) Radar Radar, Air Search, 2D Medium-Range Max Range: 277.8 km |
| China Type 775 [LLVT] - (Group, Surveillance-Only, GDG-775) Visual LLTV, Surveillance Camera Max Range: 55.6 km |
| China Type 775 [RO Radar] - (Group, Surveillance-Only, GDG-775) Radar Radar, Range-Only (RO) Max Range: 14.8 km |
| China Type 775 [Laser Rangefinder] - (Group, Surveillance-Only, GDG-775) Laser Rangefinder Laser Rangefinder Max Range: 0 km |
| China Type 775 [IR] - (Group, Surveillance-Only, GDG-775) Infrared Infrared, Surveillance Camera Max Range: 55.6 km |
| China Type 826 - (HZ100, Assoc w Type 984/985 Jammer) ESM ELINT Max Range: 222.2 km |
| China Type 984 [ECM] - (RAMSES) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
| China Type 984 [RWR] - (RAMSES) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| Weapons: |
|---|
| China Type 65 ASW Rocket Salvo [6 rnds] -
Rocket Subsurface Max: 1.9 km. |
| YJ-83 [C-802A, CSS-N-8 Saccade] -
(1999) Guided Weapon Surface Max: 185.2 km. |
| 100mm/55 H/PJ-87 Twin HECVT Burst [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 13 km. Land Max: 13 km. |
| 100mm/55 H/PJ-87 Twin HE Burst [2 rnds] -
Gun Surface Max: 13 km. Land Max: 13 km. |
| Yu-7 -
(China, 1998?) Torpedo Subsurface Max: 3.7 km. |
| Generic Chaff Rocket -
(Ship-only) Decoy (Expendable) Surface Max: 1.9 km. |
| HQ-7 Crotale [FM-80] Naval -
(China, 1990, CSA-4) Guided Weapon Air Max: 9.3 km. Surface Max: 9.3 km. |
| 37mm/63 Twin Burst [20 rnds] -
Gun Air Max: 1.9 km. Surface Max: 2.8 km. |
