General data:
Type: FFG - Guided Missile Frigate Max Speed: 28 kt
Crew: 90 Length: 84 m
Beam: 10.3 m Draft: 3.1 m
Displacement Full: 1320 t Displacement: 1100 t
Operator: Navy Commissioned: 1991
Propulsion: 1x MTU 20V 956 TB82 Diesel, 1x General Electric LM-2500 Gas Turbine, CODOG
Sensors / EW:
PMS 26 - (Modified Type 195, Type 164/174 Replacement) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 5.6 km
Scanter 009 - (Modified Type 195, Type 164/174 Replacement) Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
AWS.5 - (Modified Type 195, Type 164/174 Replacement) Radar
Radar, Air & Surface Search, 2D Short-Range
Max Range: 92.6 km
Telegon [Generic] - (For ships with unspecified Telegon gear) ESM
HF/DF
Max Range: 926 km
AN/AAQ-22 BRITE Star - (Navalized) Infrared
Infrared, Surveillance Camera
Max Range: 55.6 km
9LV200 Mk1 [Radar] - (Group, PE 723 Radar, 9LV202, 212, 218, RAKEL 203, ArtE-722) Radar
Radar, FCR, Weapon Director
Max Range: 14.8 km
9LV200 Mk1 [Laser Rangefinder] - (Group, PE 723 Radar, 9LV202, 212, 218, RAKEL 203, ArtE-722) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
9LV200 Mk1 [IR] - (Group, PE 723 Radar, 9LV202, 212, 218, RAKEL 203, ArtE-722) Infrared
Infrared, Weapon Director Camera
Max Range: 148.2 km
9LV200 Mk1 [TV Camera] - (Group, PE 723 Radar, 9LV202, 212, 218, RAKEL 203, ArtE-722) Visual
Visual, Weapon Director TV Camera
Max Range: 148.2 km
9GA209 [9GR600] - (9LV200 Mk2) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 55.6 km
Mk95 [EO] - (Mk6 Mod 0, Mk91 FCS) Visual
Visual, Target Tracking and Identification TV Camera
Max Range: 148.2 km
Mk95 [Radar] - (MFCR, Mk91 FCS) Radar
Radar Illuminator, Medium-Range
Max Range: 118.5 km
Weapons:
Depth Charge [Generic] - Depth Charge
Subsurface Max: 0.2 km.
20mm/70 Oerlikon Mk7 Burst [20 rnds] - Gun
Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km.
76mm/62 Compact HE Burst [4 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
RIM-7M Sea Sparrow - (1985) Guided Weapon
Air Max: 25.9 km. Surface Max: 25.9 km.
RGM-84A Harpoon IP - (1977) Guided Weapon
Surface Max: 120.4 km.
