General data:
Type: DD - Destroyer Max Speed: 30 kt
Crew: 301 Length: 152.8 m
Beam: 15.8 m Draft: 5.7 m
Displacement Full: 5885 t Displacement: 4650 t
Operator: Navy Commissioned: 1984
Propulsion: 4x Boilers, 2x Rateau Steam Turbines
Sensors / EW:
Telegon 4 - (AK 1200) ESM
HF/DF
Max Range: 926 km
ARBR 16 [DR 2000S] - (AK 1200) ESM
ELINT
Max Range: 926 km
ARBB 32B [RWR] - (Group) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
ARBB 32B [DECM] - (Group) ECM
DECM, Defensive ECM
Max Range: 0 km
DRBV 26 Jupiter II [TRS 3010] - (Group) Radar
Radar, Air Search, 2D Long-Range
Max Range: 296.3 km
DRBC 33A Castor IIC [Radar] - (Group, TRS 3204, CTD, GFCR) Radar
Radar, FCR, Surface-to-Air, Short-Range
Max Range: 29.6 km
TRAKIR [IR] - (Castor IIC) Infrared
Infrared, Target Tracking and Identification Camera
Max Range: 185.2 km
TRAKIR [TV Camera] - (Castor IIC) Visual
Visual, Target Tracking and Identification TV Camera
Max Range: 185.2 km
DUBV 23 - (SJD-9/Assoc w DSUV 43, Hull) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 14.8 km
DRBV 51B Triton [TRS 3035] - (Secondary Air Search) Radar
Radar, Air & Surface Search, 2D Short-Range
Max Range: 101.9 km
Senit 3 - (Secondary Air Search) Visual
Visual, Surveillance TV Camera
Max Range: 46.3 km
DUBV 43 - (Assoc w DSUV 23) VDS, Active/Passive Sonar
VDS, Active/Passive Variable Depth Sonar
Max Range: 14.8 km
DRBC 32D - (GFCR) Radar
Radar, FCR, Weapon Director
Max Range: 37 km
Decca 1226 - (GFCR) Radar
Radar, Surface Search & Navigation
Max Range: 88.9 km
Weapons:
Syllex Chaff - Decoy (Expendable)
Surface Max: 1.9 km.
Syllex Flare - Decoy (Expendable)
Surface Max: 1.9 km.
L5 Mod 4 - (Surface, ASW) Torpedo
Surface Max: 7.4 km. Subsurface Max: 7.4 km.
Malafon - (1967-1997) Guided Weapon
Subsurface Max: 20.4 km.
Generic GMTR [Guided Missile Training Round] - (Aka Drill Round) Training Round
100mm/55 Model 1968 PFHE - Gun
Air Max: 2.8 km. Surface Max: 13 km. Land Max: 13 km.
100mm/55 Model 1968 HE - Gun
Surface Max: 13 km. Land Max: 13 km.
20mm/70 Oerlikon Mk7 Burst [20 rnds] - Gun
Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km.
MM.38 Exocet Blk I - (1976) Guided Weapon
Surface Max: 42.6 km.
R.440N Crotale V3N - Guided Weapon
Air Max: 9.3 km. Surface Max: 9.3 km.
