| General data: | |
|---|---|
| Type: FFG - Guided Missile Frigate | Max Speed: 31 kt |
| Crew: 152 | Length: 121 m |
| Beam: 16.3 m | Draft: 4.4 m |
| Displacement Full: 3590 t | Displacement: 3200 t |
| Operator: Navy | Commissioned: 2004 |
| Propulsion: 2x MTU 16V 1163 TB93 Diesels, 1x General Electric LM-2500 Gas Turbine, CODAG |
| Sensors / EW: |
|---|
| TRS 5204 MRR - (Multi-Role Radar) Radar Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface Max Range: 70.4 km |
| UMS 4132 Kingklip - (Multi-Role Radar) Hull Sonar, Active/Passive Hull Sonar, Active/Passive Search & Track Max Range: 29.6 km |
| Shrike SME - (South Africa, Grintek) ESM ELINT Max Range: 926 km |
| RTS 6400 [Radar] - (Group) Radar Radar, FCR, Weapon Director Max Range: 59.3 km |
| RTS 6400 [IR] - (Group) Infrared Infrared, Weapon Director & Target Search, Slaved Tracking and Identification Camera Max Range: 185.2 km |
| RTS 6400 [CCD] - (Group) Visual LLTV, Weapon Director & Target Search, Slaved Tracking and Identification Max Range: 185.2 km |
| RTS 6400 [Laser Rangefinder] - (Group) Laser Rangefinder Laser Rangefinder for Weapon Director Max Range: 7.4 km |
| Scout Mk.2 - (Group) Radar Radar, Surface Search & Navigation Max Range: 44.4 km |
| Weapons: |
|---|
| 76mm/62 Super Rapido HE Burst [2 rnds] -
Gun Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km. |
| 35mm Twin Denel (LIW) Burst [20 rnds] -
Gun Air Max: 1.9 km. Surface Max: 2.8 km. Land Max: 2.8 km. |
| 20mm/70 Oerlikon Burst [20 rnds] -
Gun Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km. |
| 12.7mm/50 MG Burst [10 rnds] -
(Facility/Ship, No Anti-Air Capability) Gun Surface Max: 1.9 km. Land Max: 1.9 km. |
| Umkhonto-IR Mk1 -
(South Africa, 2004, SAM) Guided Weapon Air Max: 11.1 km. |
| MM.40 Exocet Blk II -
(1994) Guided Weapon Surface Max: 66.7 km. |
| Ultra Barricade Chaff Rocket LR -
Decoy (Expendable) Surface Max: 1.9 km. |
| Ultra Barricade Chaff -
Decoy (Expendable) Surface Max: 1.9 km. |
| Ultra Barricade Flare -
Decoy (Expendable) Surface Max: 1.9 km. |
| Mk46 NEARTIP Mod 5 -
(1984) Torpedo Subsurface Max: 7.4 km. |
