| General data: | |
|---|---|
| Type: CV - Aircraft Carrier | Max Speed: 33 kt |
| Crew: 1920 | Length: 265 m |
| Beam: 31.7 m | Draft: 7.5 m |
| Displacement Full: 32780 t | Displacement: 27307 t |
| Operator: Navy | Commissioned: 1988 |
| Propulsion: 6x Boilers, 2x Parsons Steam Turbines |
| Sensors / EW: |
|---|
| Telegon 4 - (AK 1200) ESM HF/DF Max Range: 926 km |
| Mirador V - (Radar Tracker) Radar Radar, Target Indicator, 2D Surface-to-Air Max Range: 18.5 km |
| ARBB 33 [ECM] - (Group) ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
| ARBB 33 [RWR] - (Group) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| ARBR 16 [DR 2000S] - (Group) ESM ELINT Max Range: 926 km |
| DRBV 15 Sea Tiger [TRS 3001] - (Group) Radar Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface Max Range: 133.3 km |
| DRBC 32 - (GFCR) Radar Radar, FCR, Weapon Director Max Range: 37 km |
| DRBC 33A Castor IIC [Radar] - (Group, TRS 3204, CTD, GFCR) Radar Radar, FCR, Surface-to-Air, Short-Range Max Range: 29.6 km |
| TRAKIR [IR] - (Castor IIC) Infrared Infrared, Target Tracking and Identification Camera Max Range: 185.2 km |
| TRAKIR [TV Camera] - (Castor IIC) Visual Visual, Target Tracking and Identification TV Camera Max Range: 185.2 km |
| CA/SQS-503 - (Castor IIC) Hull Sonar, Active-Only Hull Sonar, Active-Only Search Max Range: 3.7 km |
| DRBV 23B Jupiter - (THD 1077) Radar Radar, Air Search, 2D Medium-Range Max Range: 277.8 km |
| Decca 1226 - (THD 1077) Radar Radar, Surface Search & Navigation Max Range: 88.9 km |
| DRBI 10 - (THD 1077) Radar Radar, Air Search, 3D Medium-Range Max Range: 259.3 km |
| Weapons: |
|---|
| SAGAIE LEM Chaff -
Decoy (Expendable) Surface Max: 1.9 km. |
| SAGAIE LIR Flare -
Decoy (Expendable) Surface Max: 1.9 km. |
| 100mm/55 Model 1953 PFHE -
Gun Air Max: 2.8 km. Surface Max: 13 km. Land Max: 13 km. |
| 100mm/55 Model 1953 HE -
Gun Surface Max: 13 km. Land Max: 13 km. |
| 12.7mm/50 MG Burst [10 rnds] -
(Facility/Ship, No Anti-Air Capability) Gun Surface Max: 1.9 km. Land Max: 1.9 km. |
| R.440N Crotale V3N -
Guided Weapon Air Max: 9.3 km. Surface Max: 9.3 km. |
