General data:
Type: FFL - Corvette Max Speed: 31 kt
Crew: 95 Length: 88.3 m
Beam: 10 m Draft: 3 m
Displacement Full: 1220 t Displacement: 950 t
Operator: Navy Commissioned: 1986
Propulsion: 2x MTU 12V 956 TB82 Diesels, 1x General Electric LM-2500 Gas Turbine, CODOG
Sensors / EW:
K/ULQ-12K - (Korea, AR-680?) ESM
ELINT
Max Range: 926 km
PHS-32 - (Korea, AR-680?) Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search
Max Range: 7.4 km
S1810 - (Korea, AR-680?) Radar
Radar, Target Indicator, 2D Surface-to-Air & Surface-to-Surface
Max Range: 74.1 km
Matilde [Elaborate] - (Philax) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
ST1802SW [Radar] - (Group) Radar
Radar, FCR, Surface-to-Air, Short-Range
Max Range: 46.3 km
ST1802SW [IR] - (Group) Infrared
Infrared, Target Tracking and Identification Camera
Max Range: 148.2 km
LIROD Mk.1 [Optronic] - (Group, Controls 2x dual-purpose guns) Visual
Visual, Weapon Director TV Camera
Max Range: 74.1 km
Goalkeeper Tracker [Radar] - (Group, Controls 2x dual-purpose guns) Radar
Radar, FCR, Weapon Director
Max Range: 11.1 km
AN/SPS-64(V)1 [RM 1220 6X] - (20kW, USCG, 1x antenna) Radar
Radar, Surface Search & Navigation
Max Range: 118.5 km
Weapons:
Depth Charge [Generic] - Depth Charge
Subsurface Max: 0.2 km.
76mm/62 Compact HE Burst [4 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
Mk46 LWT Mod 1 - (1969, Major version) Torpedo
Subsurface Max: 5.6 km.
Protean Chaff - Decoy (Expendable)
Surface Max: 1.9 km.
Protean Flare - Decoy (Expendable)
Surface Max: 1.9 km.
40mm/70 Twin Breda Compact Burst [32 rnds] - Gun
Air Max: 2.2 km. Surface Max: 5.6 km. Land Max: 5.6 km.
Mk9 Depth Charge - (1943) Depth Charge
Subsurface Max: 0.2 km.
