General data:
Type: FF - Frigate Max Speed: 20 kt
Crew: 60 Length: 112.5 m
Beam: 14.4 m Draft: 6 m
Displacement Full: 3500 t Displacement: 2600 t
Operator: Navy Commissioned: 2005
Propulsion: 3x M.A.N.-Burmeister & Wain 12V 28/32 Diesels
Sensors / EW:
CTS-36 RDN - Hull Sonar, Active-Only
Hull Sonar, Active-Only Shallow Water Mine & Obstacle Avoidance
Max Range: 0.9 km
Scanter 009 - Radar
Radar, Surface Search & Navigation
Max Range: 46.3 km
AWS.6 Dolphin - Radar
Radar, Air & Surface Search, 2D Short-Range
Max Range: 55.6 km
Furuno FR-1505DA - Radar
Radar, Surface Search & Navigation
Max Range: 37 km
TSM 2640 Salmon - Hull Sonar, Active/Passive
Hull Sonar, Active/Passive Search & Track
Max Range: 7.4 km
Scorpion - ECM
OECM & DECM, Offensive & Defensive ECM
Max Range: 0 km
Telegon [Generic] - (For ships with unspecified Telegon gear) ESM
HF/DF
Max Range: 926 km
AN/AAQ-22 BRITE Star - (Navalized) Infrared
Infrared, Surveillance Camera
Max Range: 55.6 km
Type 242 Sabre - (Mermaid, Kestrel, Orange Reaper, Harpoon OTH targeting) ESM
ELINT w/ OTH Targeting
Max Range: 926 km
CEROS 200 Tracker [9LV Mk3 Basic] - (Group, PE 723 Radar, 9GR400) Radar
Radar, FCR, Surface-to-Air & Surface-to-Surface, Short-Range
Max Range: 46.3 km
EOS 500 [CCD] - (Group, PE 723 Radar, 9GR400) Visual
LLTV, Weapon Director
Max Range: 185.2 km
EOS 500 [IR Camera] - (Group, PE 723 Radar, 9GR400) Infrared
Infrared, Weapon Director Camera
Max Range: 185.2 km
EOS 500 [Laser Rangefinder] - (Group, PE 723 Radar, 9GR400) Laser Rangefinder
Laser Rangefinder for Weapon Director
Max Range: 7.4 km
Weapons:
Depth Charge [Generic] - Depth Charge
Subsurface Max: 0.2 km.
76mm/62 Super Rapido HE Burst [2 rnds] - Gun
Air Max: 2.8 km. Surface Max: 11.1 km. Land Max: 11.1 km.
20mm/70 Oerlikon Mk7 Burst [20 rnds] - Gun
Air Max: 1.5 km. Surface Max: 1.9 km. Land Max: 1.9 km.
Chimera Chaff/Flare Seduction Round - Decoy (Expendable)
Surface Max: 1.9 km.
