| General data: | |
|---|---|
| Type: CV - Aircraft Carrier | Max Speed: 32 kt |
| Crew: 1450 | Length: 284 m |
| Beam: 39 m | Draft: 11 m |
| Displacement Full: 65600 t | Displacement: 60000 t |
| Operator: Royal Navy | Commissioned: 2018 |
| Propulsion: 4x Wartsila 38 Diesels (2x 12V38 + 2x 16V38), 2x Rolls-Royce Marine Trent MT30 Gas Turbines, CODLAG |
| Sensors / EW: |
|---|
| Type 1007 - (1988, KH 1007) Radar Radar, Surface Search & Navigation Max Range: 177.8 km |
| UAT-2.0 Sceptre XL - (Upgraded, Type 45) ESM ELINT Max Range: 926 km |
| IRAS [CCD] - (Group, IR Alerting System) Visual LLTV, Target Search, Slaved Tracking and Identification Max Range: 185.2 km |
| IRAS [IR] - (Group, IR Alerting System) Infrared Infrared, Target Search, Slaved Tracking and Identification Camera Max Range: 185.2 km |
| IRAS [Laser Rangefinder] - (Group, IR Alerting System) Laser Rangefinder Laser Rangefinder Max Range: 0 km |
| Type 997 Artisan 3D - (2013) Radar Radar, Target Indicator, 3D Surface-to-Air Max Range: 203.7 km |
| Type 1046 VSR/LRR [S.1850M, BMD Mod] - (RAN-40S, RAT-31DL, SMART-L Derivative) Radar Radar, Air Search, 3D Long-Range Max Range: 2000.2 km |
| Weapons: |
|---|
| Mk216 Sea Gnat Chaff [Distraction] -
(1988) Decoy (Expendable) Surface Max: 1.9 km. |
| Mk245A2 TALOS Flare -
(2000) Decoy (Expendable) Surface Max: 1.9 km. |
| Mk214 Sea Gnat Chaff [Seduction] -
(1987) Decoy (Expendable) Surface Max: 1.9 km. |
| Mk251 Siren Active Decoy Round -
(2004) Decoy (Expendable) Surface Max: 1.9 km. |
| 30mm/75 DS30M Mk2 APDS Burst [20 rnds] -
Gun Air Max: 1.9 km. Surface Max: 2.8 km. Land Max: 2.8 km. |
| 30mm/75 DS30M Mk3 HE Burst [20 rnds] -
Gun Air Max: 1.9 km. Surface Max: 2.8 km. Land Max: 2.8 km. |
| 20mm/100 Mk15 Phalanx Blk 1B Burst [300 rnds] -
Gun Air Max: 1.5 km. Surface Max: 1.9 km. |
