OVERVIEW: The AN/FPS-113 is a fixed, 2-D early warning and ground-controlled interception radar system operating in the "D" Band
DETAILS: The AN/FPS-113 is a modified AN/FPS-20.
Specifications:
Frequency: 1250 to 1350 MHz (NATO D Band)(IEEE: L Band)
Power output: 6 KW (average); 2.5 MW (peak)
PRF: 350 Hz
Range Resolution: 1.85 km (range), 1 degree (azimuth)
On/Off time: unknown
Deploy/Stow Time N/A
Max Range: 322 km
NOTES: The radar family started with the AN/FPS-3 in 1950. The AN/FPS-113 is a modified AN/FPS-20, created by General Dynamics modifying the FPS-20 with a new digital moving target indicator (MTI) system, producing the AN/FPS-113.
