General data:
Type: Mobile Vehicle(s) Crew: 1
Length: 0 m Width: 0 m
Operator: Surface-to-Air Missile Corps Commissioned: 2002
Sensors / EW:
HT-233 [HQ-9A] - (Tombstone) Radar
Radar, FCR, Surface-to-Air, Medium-Range
Max Range: 166.7 km
China YLC-2V [High Guard] - (Early Warning) Radar
Radar, Air Search, 3D Long-Range
Max Range: 500 km
China Type 347G [TR-47C, Radar Tracker] - (Goalkeeper, Type 730 CIWS) Radar
Radar, FCR, Weapon Director
Max Range: 11.1 km
Generic Target Indicator, 3D Surface-to-Air, Surface-to-Surface - (Goalkeeper, Type 730 CIWS) Radar
Radar, Target Indicator, 3D Surface-to-Air & Surface-to-Surface
Max Range: 37 km
OFC-3 [TV Camera] - (Goalkeeper, Type 730 CIWS) Visual
Visual, Weapon Director & Target Tracking and Identification TV Camera
Max Range: 185.2 km
OFC-3 [LLTV] - (Goalkeeper, Type 730 CIWS) Visual
LLTV, Weapon Director & Target Tracking and Identification
Max Range: 185.2 km
OFC-3 [IR] - (Goalkeeper, Type 730 CIWS) Infrared
Infrared, Weapon Director & Target Tracking and Identification Camera
Max Range: 185.2 km
OFC-3 [Laser Rangefinder] - (Goalkeeper, Type 730 CIWS) Laser Rangefinder
Laser Rangefinder
Max Range: 14.8 km
Weapons:
HQ-9A - (China) Guided Weapon
Air Max: 148.2 km.
30mm China H/PJ-12 [Type 730, 240 rnds] - (China, Goalkeeper Copy) Gun
Air Max: 1.9 km. Surface Max: 2.8 km.
