General data: | |
---|---|
Type: Recon | Crew: 2 |
Min Speed: 350 kt | Max Speed: 920 kt |
Wingspan: 11.7 m | Height: 5.02 m |
Length: 19.2 m | Max Payload: 8480 kg |
Empty Weight: 13755 kg | Max Weight: 28030 kg |
Operator: Air Self-Defense Force | Commissioned: 1992 |
Propulsion: 2x J79-GE-17 | Decommissioned: 2020 |
Sensors / EW: |
---|
J/APR-5 - ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
AN/APD-102 - Radar SLAR, Side-Looking Airborne Radar Max Range: 74.1 km |
KS-87 Frame Camera - Visual Visual, Reconnaissance Frame Camera Max Range: 9.3 km |
KA-91 Panoramic Camera - Visual Visual, Reconnaissance Frame Camera Max Range: 9.3 km |
AN/AAD-5/RS-720 - Infrared Infrared, Reconnaissance Frame Camera Max Range: 9.3 km |
AN/APQ-172 - Radar Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range Max Range: 74.1 km |
J/ALQ-6 - ECM OECM & DECM, Offensive & Defensive ECM Max Range: 0 km |
Weapons / Loadouts: |
---|
370 USG Drop Tank -
Drop Tank |
AN/ALQ-119 DECM Pod -
Sensor Pod |
600 USG Drop Tank -
Drop Tank |
