| General data: | |
|---|---|
| Type: Maritime Patrol Aircraft (MPA) | Crew: 11 |
| Min Speed: 250 kt | Max Speed: 470 kt |
| Wingspan: 53.1 m | Height: 12.2 m |
| Length: 49.5 m | Max Payload: 15000 kg |
| Empty Weight: 91800 kg | Max Weight: 155000 kg |
| Operator: Navy | Commissioned: 1994 |
| Propulsion: 4x NK-12MP |
| Sensors / EW: |
|---|
| Wet Eye [Korshun-KN-N] - Radar Radar, Surface Search, Medium-Range Max Range: 277.8 km |
| MAD [MMS-106 Ladoga] - (Tu-142MK) MAD MAD Max Range: 1.9 km |
| ELINT [Kvadrat-2] - (Il-20M, Tu-95RT, Fine Analysis) ESM ELINT Max Range: 926 km |
| Box Tail [PRS-4 Krypton] - (Il-20M, Tu-95RT, Fine Analysis) Radar TWR, Tail Warning Radar & Tail Gun Director Max Range: 18.5 km |
| SPO-32 Pastel [L-150] - (Il-20M, Tu-95RT, Fine Analysis) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| L-082 Mak-UT - (Tu-95MS) Infrared MAWS, Missile Approach Warning System Max Range: 9.3 km |
| SPS-160 Geran - (Tu-95MS) ECM DECM, Defensive ECM Max Range: 0 km |
| Generic Tail Gun Director [TV Camera] - (2nd Gen) Visual Visual, Weapon Director TV Camera Max Range: 185.2 km |
| Weapons / Loadouts: |
|---|
| APR-2 Orlan-M -
(1982, Aircraft & Helos) Torpedo Subsurface Max: 0.9 km. |
| AT-3 [UMGT-1 Orlan, NATO E40-79A] -
(1982) Torpedo Subsurface Max: 1.9 km. |
| RGB-75 [Basic Search, Passive Omni] -
(Korshun System, 150m, 5hr, Primary Type, LOFAR) Sonobuoy |
| RGB-15 [Refined Search, Passive Omni] -
(Korshun System, 20/150/400m, 2hr, Straight/Curved Barrier) Sonobuoy |
| RGB-25 [Track, Passive Directional] -
(Korshun System, 20/150m, 45min) Sonobuoy |
| RGB-55A [Track, Active/Passive] -
(Korshun System, 20/200m, 2hr) Sonobuoy |
