| General data: | |
|---|---|
| Type: Area Surveillance | Crew: 5 |
| Min Speed: 140 kt | Max Speed: 325 kt |
| Wingspan: 40.4 m | Height: 11.6 m |
| Length: 29.8 m | Max Payload: 19090 kg |
| Empty Weight: 34400 kg | Max Weight: 70300 kg |
| Operator: Air Force | Commissioned: 1992 |
| Propulsion: 4x T56-A-15 |
| Sensors / EW: |
|---|
| AN/AAR-44 - Infrared MAWS, Missile Approach Warning System Max Range: 9.3 km |
| AN/ALR-69 - ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| AN/APQ-170(V)8 - Radar Radar, Ground Mapping Max Range: 92.6 km |
| AN/ALQ-172(V)1 - (MC-130H, AC-130U) ECM DECM, Defensive ECM Max Range: 0 km |
| AN/AAQ-17 - (MC-130H, AC-130U) Infrared Infrared, Surveillance & Navigation Camera Max Range: 55.6 km |
| Weapons / Loadouts: |
|---|
| Paratrooper -
Paratroops |
| Delta Force Para -
Paratroops |
| Green Berets Para -
Paratroops |
| Ranger -
Troops |
| Cargo [No Drop, 19 tons] -
Cargo |
| Cargo [No Drop, 16 tons] -
Cargo |
| Cargo [No Drop, 10 tons] -
Cargo |
| Cargo [Air Drop, 10 tons] -
Cargo |
