| General data: | |
|---|---|
| Type: Area Surveillance | Crew: 5 |
| Min Speed: 120 kt | Max Speed: 325 kt |
| Wingspan: 39.7 m | Height: 11.9 m |
| Length: 29.3 m | Max Payload: 19090 kg |
| Empty Weight: 34400 kg | Max Weight: 69750 kg |
| Operator: Air Force | Commissioned: 1973 |
| Propulsion: 4x T56-A-7A |
| Sensors / EW: |
|---|
| AN/ALQ-87 - ECM DECM, Defensive ECM Max Range: 0 km |
| AN/ALR-69 - ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| AN/APQ-122(V)8 - Radar Radar, Ground Mapping Max Range: 277.8 km |
| Weapons / Loadouts: |
|---|
| Delta Force Para -
Paratroops |
| Green Berets Para -
Paratroops |
| Ranger -
Troops |
| Paratrooper -
Paratroops |
| Trooper -
Troops |
| Cargo [No Drop, 19 tons] -
Cargo |
| Cargo [No Drop, 16 tons] -
Cargo |
| Cargo [No Drop, 10 tons] -
Cargo |
| Cargo [Air Drop, 10 tons] -
Cargo |
| BLU-82/B Commando Vault / Daisy Cutter -
Bomb Land Max: 1.9 km. |
