| General data: | |
|---|---|
| Type: Attack | Crew: 2 |
| Min Speed: 350 kt | Max Speed: 750 kt |
| Wingspan: 17.6 m | Height: 5.9 m |
| Length: 22.7 m | Max Payload: 8100 kg |
| Empty Weight: 21150 kg | Max Weight: 37900 kg |
| Operator: Frontal Aviation [VVS] | Commissioned: 1981 |
| Propulsion: 2x AL-21F-3A |
| Sensors / EW: |
|---|
| Bomb Sight [EOV Chaika-1] - (Su-24) Visual Visual, Bomb Sight Max Range: 3.7 km |
| Emitter Location System [PRP Filin-N] - (Su-24 AS-9 Targeting) ESM Emitter Locator (For ARM Missiles) Max Range: 222.2 km |
| SPS-161 Geran [L-101] - (Su-24) ECM DECM, Defensive ECM Max Range: 0 km |
| Drop Kick [RPO Orion] - (Su-24) Radar Radar, FCR, Air-to-Surface, Medium-Range Max Range: 148.2 km |
| SPO-10 Sirena-3M - (Su-24) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| Weapons / Loadouts: |
|---|
| OFAB-100-120 Frag -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| FAB-250M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| FAB-500M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| RBK-250-PTAB CB [30 x PTAB-2.5 Anti-Tank Bomblets] -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| RBK-500-BetAB CB [12 x BetAB-20 Anti-Runway Penetrator Bomblets] -
Bomb Land Max: 1.9 km. |
| RBK-500-ZAB [117 x ZAB-2.5SM Incendiary] -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| RBK-500-PTAB [268 x PTAB-1M Anti-Tank Bomblets] -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| 3000 liter Drop Tank -
Drop Tank |
| FAB-100M-62 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| FAB-250M-62 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| FAB-500M-62 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| FAB-1500M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| AA-8 Aphid [R-60] -
(1974) Guided Weapon Air Max: 9.3 km. |
| S-5K 57mm Rocket -
(OOS ~2014, Superseded by S-8) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
| S-24B 240mm Rocket -
(V-24A Fuze) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
| AA-8 Aphid [R-60M] -
(1983) Guided Weapon Air Max: 9.3 km. |
| OFAB-250-270 Frag -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| AS-7 Kerry [Kh-23] -
(1971) Guided Weapon Surface Max: 10 km. Land Max: 10 km. |
| AS-9 Kyle [Kh-28] -
(1974) Guided Weapon Surface Max: 120.4 km. Land Max: 120.4 km. |
| RN-28 Tactical Bomb [1kT Nuclear] -
(Russia, 8U49, Su-24) Bomb Surface Max: 5.6 km. Land Max: 5.6 km. |
| RN-40 Tactical Bomb [30kT Nuclear] -
(Russia, 8U-64, MiG-23, MiG-27, MiG-29 (9-12)) Bomb Surface Max: 5.6 km. Land Max: 5.6 km. |
