General data: | |
---|---|
Type: Multirole (Fighter/Attack) | Crew: 2 |
Min Speed: 350 kt | Max Speed: 920 kt |
Wingspan: 9.5 m | Height: 4.8 m |
Length: 14.5 m | Max Payload: 6894 kg |
Empty Weight: 7395 kg | Max Weight: 19200 kg |
Operator: Air Force | Commissioned: 1991 |
Propulsion: 1x F100-PW-200 |
Sensors / EW: |
---|
AN/APG-66 - Radar Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range Max Range: 74.1 km |
AN/ALR-69 - ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
Weapons / Loadouts: |
---|
300 USG Drop Tank -
Drop Tank |
370 USG Drop Tank -
Drop Tank |
AN/ALQ-131 DECM Pod -
(1983?) Sensor Pod |
AIM-9P-4 Sidewinder -
(1980) Guided Weapon Air Max: 18.5 km. |
AIM-9L Sidewinder -
(1980) Guided Weapon Air Max: 18.5 km. |
Mk82 500lb LDGP -
(1954) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
Mk84 2000lb LDGP -
(1955) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
Mk20 Rockeye II CB [247 x Mk118 Dual Purpose Bomblets] -
(1969, Mk7 Dispenser) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
HYDRA 70mm Rocket -
(Mk 66 Rocket, M229 Warhead, M423/7 Fuze) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
Atlis Pod [EO + LRMTS, 12k ft] -
(1980) Sensor Pod |
AS.30L -
(1989) Guided Weapon Surface Max: 11.1 km. Land Max: 11.1 km. |
R.550 Magic 2 Mk1 -
(1986) Guided Weapon Air Max: 14.8 km. |
