| General data: | |
|---|---|
| Type: Attack | Crew: 2 |
| Min Speed: 55 kt | Max Speed: 160 kt |
| Wingspan: 4.53 m | Height: 5.2 m |
| Length: 13.85 m | Max Payload: 1195 kg |
| Empty Weight: 4100 kg | Max Weight: 6400 kg |
| Operator: Army | Commissioned: 2012 |
| Propulsion: 2x MTR 390-2C |
| Sensors / EW: |
|---|
| TWE [LWR] - (NH90, Tiger, Threat Warning Equipment) ESM LWR, Laser Warning Receiver Max Range: 11.1 km |
| AN/AAR-60 PMAWS - (MILDS F) Infrared MAWS, Missile Approach Warning System Max Range: 9.3 km |
| TWE [RWR] - (NH90, Tiger, Threat Warning Equipment) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| Osiris [CCD] - (Group, UHT) Visual LLTV, Weapon Director & Target Search, Tracking and Identification Max Range: 55.6 km |
| Osiris [FLIR] - (Group, UHT) Infrared Infrared, Weapon Director & Target Search, Tracking and Identification Camera Max Range: 55.6 km |
| Osiris [Laser Designator] - (Group, UHT) Laser Designator Laser Rangefinder for Weapon Director / Target Tracking and Identification Max Range: 27.8 km |
| AN/AVS-9 Night Vision Goggles - (Group, UHT) Visual LLTV, Night Vision Goggles (NVG) Max Range: 27.8 km |
| Weapons / Loadouts: |
|---|
| 12.7mm/50 MG Burst [20 rnds] -
(Aircraft, No Anti-Air Capability) Gun Surface Max: 1.9 km. Land Max: 1.9 km. |
| HYDRA 70mm Rocket -
(Mk 66 Rocket, M229 Warhead, M423/7 Fuze) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
| HOT 3 -
(1994) Guided Weapon Surface Max: 5.6 km. Land Max: 5.6 km. |
| AIM-92C Stinger ATAS RPM -
(1992) Guided Weapon Air Max: 5.6 km. |
| 367 liter Ferry Tank -
Ferry Tank |
| PARS-3LR [TRIGAT-LR] -
(2012+, Germany) Guided Weapon Surface Max: 7.4 km. Land Max: 7.4 km. |
