| General data: | |
|---|---|
| Type: Attack | Crew: 1 |
| Min Speed: 350 kt | Max Speed: 570 kt |
| Wingspan: 8.9 m | Height: 4.6 m |
| Length: 13.6 m | Max Payload: 3800 kg |
| Empty Weight: 6730 kg | Max Weight: 13000 kg |
| Operator: Air Force | Commissioned: 2015 |
| Propulsion: 1x Spey RB.168 Mk.807 |
| Sensors / EW: |
|---|
| MM/SCP-01 Scipio - (AMX) Radar Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range Max Range: 55.6 km |
| ELT-553 - (AMX) ECM DECM, Defensive ECM Max Range: 0 km |
| Generic FLIR - (DEPRECATED - 2nd Gen, Surveillance, 8x Magnification) Infrared Infrared, Surveillance Camera Max Range: 55.6 km |
| ELT-156X(V) - (AMX) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| Weapons / Loadouts: |
|---|
| MAA-1 Piranha -
(2004) Guided Weapon Air Max: 14.8 km. |
| 1100 liter Drop Tank -
Drop Tank |
| Mk82 500lb LDGP -
(1954) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| Mk83 1000lb LDGP -
(1954) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| HYDRA 70mm Rocket -
(Mk 66 Rocket, M229 Warhead, M423/7 Fuze) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
| 580 liter Drop Tank -
Drop Tank |
| MAR-1 [ARM] -
Guided Weapon Surface Max: 50 km. Land Max: 50 km. |
| Skyshield OECM Pod -
(Israel) Sensor Pod |
| Litening III Pod [FLIR + LRMTS, 40k ft] -
Sensor Pod |
| Lizard 2 LGB [Mk82] -
(1998, Israel) Guided Weapon Surface Max: 7.4 km. Land Max: 7.4 km. |
| SMKB-83 -
(Mk83 1000lb) Guided Weapon Surface Max: 50 km. Land Max: 50 km. |
| SMKB-82 -
(Mk82 500lb) Guided Weapon Surface Max: 50 km. Land Max: 50 km. |
