General data:
Type: Attack Crew: 2
Min Speed: 55 kt Max Speed: 160 kt
Wingspan: 3.0 m Height: 4.9 m
Length: 16.0 m Max Payload: 2000 kg
Empty Weight: 7700 kg Max Weight: 10800 kg
Operator: Army Commissioned: 2012
Propulsion: 2x VK-2500
Sensors / EW:
FH01 Arbalet 52 - (Ka-52 Nose Radar) Radar
Radar, FCR, Air-to-Air & Air-to-Surface, Short-Range
Max Range: 37 km
GOES-451 [IR] - (Ka-52 Nose Radar) Infrared
Infrared, Weapon Director & Target Search, Tracking and Identification Camera
Max Range: 55.6 km
GOES-451 [LLTV] - (Ka-52 Nose Radar) Visual
LLTV, Weapon Director & Target Search, Tracking and Identification
Max Range: 83.3 km
GOES-451 [Laser Designator/Rangefinder] - (Ka-52 Nose Radar) Laser Designator
Laser Target Designator & Ranger (LTD/R)
Max Range: 18.5 km
GOES-451 [Laser Spot Tracker] - (Ka-52 Nose Radar) Laser Spot Tracker (LST)
LST, Laser Spot Tracker
Max Range: 14.8 km
SPO-32 Pastel [L-150] - (Ka-52 Nose Radar) ESM
RWR, Radar Warning Receiver
Max Range: 222.2 km
L-140 Otklik - (Ka-52 Nose Radar) ESM
LWR, Laser Warning Receiver
Max Range: 11.1 km
L-136 Mak-UFM - (Ka-52 Nose Radar) Infrared
MAWS, Missile Approach Warning System
Max Range: 14.8 km
L-370-3 Vitebsk [DECM] - (Ka-52 Nose Radar) ECM
DECM, Defensive ECM
Max Range: 0 km
L-370-5 Vitebsk [DIRCM] - (Ka-52 Nose Radar) ECM
IRCM
Max Range: 0 km
Weapons / Loadouts:
AT-9 Spiral-2 [9M120 Ataka-V] - Guided Weapon
Surface Max: 9.3 km. Land Max: 9.3 km.
S-8KO 80mm Rocket [HEAT] - (1985) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
Igla-V - (9K338 Igla, Air-to-Air) Guided Weapon
Air Max: 5.6 km.
S-13B 122mm Rocket [Penetrator] - (1984) Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
S-5K 57mm Rocket - Rocket
Surface Max: 3.7 km. Land Max: 3.7 km.
AT-16 Scallion [9K121 Vikhr] - (1993, Not 9M120 Ataka-V) Guided Weapon
Surface Max: 9.3 km. Land Max: 9.3 km.
