General data: | |
---|---|
Type: Recon | Crew: 2 |
Min Speed: 120 kt | Max Speed: 245 kt |
Wingspan: 14.6 m | Height: 3.9 m |
Length: 12.5 m | Max Payload: 0 kg |
Empty Weight: 5467 kg | Max Weight: 8214 kg |
Operator: Army | Commissioned: 1996 |
Propulsion: 2x T53-L-701A |
Sensors / EW: |
---|
AN/APR-44 - (Continuous-Wave RWR) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
AN/ALQ-136(V)2 - (Pulse-Radar Jammer) ECM DECM, Defensive ECM Max Range: 0 km |
AN/ALQ-147 Hot Brick - (Pulse-Radar Jammer) ECM IRCM Max Range: 0 km |
AN/APR-32(V)2 - (Pulse-Radar RWR) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
KA-30 Panoramic Camera - (Pulse-Radar RWR) Visual Visual, Reconnaissance Frame Camera Max Range: 9.3 km |
KA-60 Panoramic Camera - (Pulse-Radar RWR) Visual Visual, Reconnaissance Frame Camera Max Range: 9.3 km |
KA-76 Serial Frame Camera - (Pulse-Radar RWR) Visual Visual, Reconnaissance Frame Camera Max Range: 9.3 km |
AN/ALQ-162 Shadowbox - (Continuous-Wave-Radar Jammer) ECM DECM, Defensive ECM Max Range: 0 km |
Weapons / Loadouts: |
---|
AN/APS-94F Recon Pod [SLAR] -
Sensor Pod |
AN/AUS-24 Recon Pod [IR] -
Sensor Pod |
