General data:
Type: Maritime Patrol Aircraft (MPA) Crew: 10
Min Speed: 205 kt Max Speed: 410 kt
Wingspan: 30.4 m Height: 10.3 m
Length: 35.6 m Max Payload: 9070 kg
Empty Weight: 27890 kg Max Weight: 61235 kg
Operator: Navy Commissioned: 1984
Propulsion: 4x T56-A-14
Sensors / EW:
AN/APS-115 - Radar
Radar, Surface Search, Long-Range
Max Range: 370.4 km
AN/AAS-36 IRDS - (P-3C Update II) Infrared
Infrared, Surveillance Camera
Max Range: 55.6 km
AN/ALQ-78 - (P-3C Update II) ESM
ELINT
Max Range: 926 km
AN/ASQ-81(V)1 - (P-3C) MAD
MAD
Max Range: 1.9 km
Weapons / Loadouts:
Mk46 LWT Mod 2 - (1972) Torpedo
Subsurface Max: 5.6 km.
AN/SSQ-53A DIFAR - (A-Size, 31 Chn, 27m/304m) Sonobuoy
AN/SSQ-62A DICASS - (1979, A-Size, 31 Chn, 27/457m, 1hr) Sonobuoy
AN/SSQ-77A VLAD - (1981-2002, A-Size, 99 Chn, 152/305m, 1/4/8hrs) Sonobuoy
Mk46 NEARTIP Mod 5 - (1984) Torpedo
Subsurface Max: 7.4 km.
AGM-84C Harpoon IB - (1983) Guided Weapon
Surface Max: 120.4 km.
Mine [Mk52 1000lb] - (1962) Bottom Mine
Mine [Mk55 2000lb] - (1962, 180m max depth) Bottom Mine
Mine [Mk62 Quickstrike Mk82] - (1982) Bottom Mine
Mine [Mk65 Mod 0 Quickstrike 2000lb] - (1984, 90m max depth) Bottom Mine
Mine [Mk63 Quickstrike Mk83] - (1982) Bottom Mine
Mine [Mk60 CAPTOR Encapsulated Torpedo] - (1981) Rising Mine
Subsurface Max: 2.8 km.
B57 Multipurpose Sub Bomb [20kT Nuclear] - (Aerial) Depth Charge
Subsurface Max: 0.9 km.
