| General data: | |
|---|---|
| Type: Multirole (Fighter/Attack) | Crew: 2 |
| Min Speed: 350 kt | Max Speed: 920 kt |
| Wingspan: 13.1 m | Height: 4.65 m |
| Length: 19.3 m | Max Payload: 7260 kg |
| Empty Weight: 14390 kg | Max Weight: 32000 kg |
| Operator: Royal Air Force | Commissioned: 2016 |
| Propulsion: 2x F110-GE-129 |
| Sensors / EW: |
|---|
| AN/ALR-56C TEWS - ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| AN/APG-63(V)3 AESA - (LPI) Radar Radar, FCR, Air-to-Air & Air-to-Surface, Long-Range Max Range: 296.3 km |
| AN/AVS-9 Night Vision Goggles - (LPI) Visual LLTV, Night Vision Goggles (NVG) Max Range: 27.8 km |
| AN/AAR-57 CMWS - (Common Missile Warning System) Infrared MAWS, Missile Approach Warning System Max Range: 9.3 km |
| AN/ALQ-239 DEWS - (Common Missile Warning System) ECM DECM, Defensive ECM Max Range: 0 km |
| Weapons / Loadouts: |
|---|
| 750 USG CFT -
Ferry Tank |
| 600 USG Drop Tank -
Drop Tank |
| AIM-9X Sidewinder -
(2005) Guided Weapon Air Max: 25.9 km. |
| AN/ALQ-131 DECM Pod -
(1983?) Sensor Pod |
| AIM-120C-7 AMRAAM P3I.3 -
(2007) Guided Weapon Air Max: 120.4 km. |
| Tiger Eyes Pod [IRST] -
(LANTIRN Gen 3, Sniper XP Pylon) Sensor Pod |
| AN/AAQ-33 Sniper XR Pod [FLIR + LRMTS, 40k ft] -
(2005) Sensor Pod |
| AGM-65D Maverick IR -
(1984) Guided Weapon Surface Max: 14.8 km. Land Max: 14.8 km. |
| Tiger Eyes Pod [FLIR, CCD TV + TFR] -
(LANTIRN Gen 3) Sensor Pod |
| AGM-65G Maverick IR -
(1991) Guided Weapon Surface Max: 14.8 km. Land Max: 14.8 km. |
| CBU-105 WCMD [CBU-97/B SFW, 10 x BLU-108/B Anti-Tank Bomblets] -
(2000, CBU-97) Guided Weapon Land Max: 27.8 km. |
| GBU-10E/B Paveway II LGB [Mk84] -
(USAF) Guided Weapon Surface Max: 7.4 km. Land Max: 7.4 km. |
| GBU-12D/B Paveway II LGB [Mk82] -
Guided Weapon Surface Max: 7.4 km. Land Max: 7.4 km. |
| AN/AXQ-14 Datalink Pod -
Sensor Pod |
| GBU-15(V)2/B CWW IIR [Mk84] -
(1986) Guided Weapon Surface Max: 27.8 km. Land Max: 27.8 km. |
| Mk82 500lb LDGP -
(1954) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| Mk84 2000lb LDGP -
(1955) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| GBU-24E/B Paveway III GPS/LGB [BLU-109A/B] -
(USN, 2001) Guided Weapon Surface Max: 14.8 km. Land Max: 14.8 km. |
| GBU-31(V)3/B JDAM [BLU-109/B] -
(USAF) Guided Weapon Land Max: 24.1 km. |
| CBU-103 WCMD [CBU-87/B CEM, 202 x BLU-97/B Dual-Purpose Bomblets] -
(2000) Guided Weapon Land Max: 27.8 km. |
| AGM-84L Harpoon II -
(2003) Guided Weapon Surface Max: 138.9 km. Land Max: 138.9 km. |
| AGM-88C HARM -
(1994) Guided Weapon Surface Max: 129.6 km. Land Max: 129.6 km. |
| GBU-49/B Paveway II GPS/LGB [Mk82] -
Guided Weapon Surface Max: 7.4 km. Land Max: 7.4 km. |
