| General data: | |
|---|---|
| Type: Fighter | Crew: 1 |
| Min Speed: 350 kt | Max Speed: 920 kt |
| Wingspan: 9.3 m | Height: 5.4 m |
| Length: 21.6 m | Max Payload: 0 kg |
| Empty Weight: 9820 kg | Max Weight: 17800 kg |
| Operator: PLANAF | Commissioned: 1996 |
| Propulsion: 2x WP-13A2 [R-13F-300 Copy] | Decommissioned: 2007 |
| Sensors / EW: |
|---|
| China KLJ-1 - (J-8D, Type 1492(?)) Radar Radar, FCR, Air-to-Air, Medium-Range Max Range: 111.1 km |
| China BM/KJ-8602A [SPS-1000] - (RW 1045) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| Weapons / Loadouts: |
|---|
| 800 liter Drop Tank -
Drop Tank |
| 1400 liter Drop Tank -
Drop Tank |
| 250kg GPB -
(Generic) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| PL-9 -
(China, 1989, Export(?)) Guided Weapon Air Max: 14.8 km. |
| 500kg GPB -
(Generic) Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| 57mm Rocket -
(Generic) Rocket Surface Max: 1.9 km. Land Max: 1.9 km. |
| 90mm Rocket -
(Generic) Rocket Surface Max: 3.7 km. Land Max: 3.7 km. |
