| General data: | |
|---|---|
| Type: Bomber | Crew: 4 |
| Min Speed: 400 kt | Max Speed: 920 kt |
| Wingspan: 34.3 m | Height: 11.1 m |
| Length: 42.5 m | Max Payload: 24000 kg |
| Empty Weight: 54000 kg | Max Weight: 124000 kg |
| Operator: Naval Aviation [AV-MF] | Commissioned: 1989 |
| Propulsion: 2x NK-25 | Decommissioned: 1991 |
| Sensors / EW: |
|---|
| Fan Tail [PRS-4KM Krypton-B] - Radar TWR, Tail Warning Radar & Tail Gun Director Max Range: 18.5 km |
| L-082 Mak-UL - (BKO-2 Karpaty EW Suite) Infrared MAWS, Missile Approach Warning System Max Range: 9.3 km |
| TP-1 Tail Gun TV Sighting System - (Tu-22M) Visual Visual, Weapon Director TV Camera Max Range: 74.1 km |
| SPS-171/172 Sorbtsiya [L-005] - (Tu-22M) ECM DECM, Defensive ECM Max Range: 0 km |
| Bomb Sight [OPB-15T Groza] - (Tu-22M, Tu-160) Visual Visual, Bomb Sight Max Range: 3.7 km |
| Avtomat 2/3 - (Tu-22M-2/3) ESM RWR, Radar Warning Receiver Max Range: 222.2 km |
| Down Beat [PNA-D Rubin] - (Tu-22M-3) Radar Radar, FCR, Air-to-Surface, Long-Range Max Range: 444.5 km |
| Weapons / Loadouts: |
|---|
| AS-4 Kitchen A Mod 3 [Kh-22N ASM, 350kT Nuclear] -
(1983? Tu-22M-2/3) Guided Weapon Surface Max: 398.2 km. |
| AS-4 Kitchen B Mod 3 [Kh-22NA INS+TERCOM, 350kT Nuclear] -
(1983? Tu-22M-2/3) Guided Weapon Land Max: 555.6 km. |
| AS-4 Kitchen A Mod 3 [Kh-22N ASM] -
(1983? Tu-22M-2/3) Guided Weapon Surface Max: 398.2 km. |
| AS-4 Kitchen B Mod 3 [Kh-22NA INS+TERCOM] -
(1983? Tu-22M-2/3) Guided Weapon Land Max: 555.6 km. |
| OFAB-100-120 Frag -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| FAB-250M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| FAB-500M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| FAB-1500M-54 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| FAB-3000M-46 GPB -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| OFAB-250-270 Frag -
Bomb Surface Max: 1.9 km. Land Max: 1.9 km. |
| RN-40 Tactical Bomb [30kT Nuclear] -
(Russia, 8U-64, MiG-23, MiG-27, MiG-29 (9-12)) Bomb Surface Max: 5.6 km. Land Max: 5.6 km. |
| RN-42 Strategic Bomb [200kT Nuclear] -
(Russia) Bomb Surface Max: 5.6 km. Land Max: 5.6 km. |
| Mine [Bottom, Acoustic Narrow-Band Fuze & Target Discrimination] -
(Advanced) Bottom Mine |
| AS-16 Kickback [Kh-15, 350kT Nuclear] -
Guided Weapon Land Max: 148.2 km. |
| AS-16 Kickback [Kh-15, Conventional] -
Guided Weapon Land Max: 148.2 km. |
| AS-16 Kickback [Kh-15S] -
(Kh-15A, ASuW) Guided Weapon Surface Max: 148.2 km. |
| AS-16 Kickback [Kh-15P] -
(ARM) Guided Weapon Surface Max: 148.2 km. Land Max: 148.2 km. |
